www.timberk.com • electrical storage water heater

1. At first, open one of the separable taps at the water heater outlet, then

open the inlet tap. The electric water heater will start filling with water.

When water flows from separable tap freely, it means the water heater is

fully filled with water and you can close the separable tap.

2. Plug the power cord into the outlet.

IMPORTANT!

The outlet must be designed for rated current not less

than 10A, electric cable with copper core must have

cross section not less than 3x1.5 mm2 (for copper).

8. WATER HEATER OPERATION

3. Turn the thermostate handle (fig. 4,5) clockwise and set the desirable

temperature. The temperature can be set from +35°C (±5°С) (MIN» position

of the thermostat knob) up to 70°C (±5°С) (rightmost «MAX» position of

the thermostat knob). To reduce the water temperature turn the handle

anticlockwise.

4. Water temperature keeps up by the thermostate automatically. When

water temperature reach the set level, Heating is automatically switched off.

At that, the indicator lamp in the lower part of the appliance extinguishes.

When the temperature be lower then set, the heating will automaticlly start

again and the indicator lamp lights up.

5. To turn off the waterheater, turn the handle to the closest left position

» and unplug the power cord or disconnect the appliance from the

power supply.

NOTE:

During normal operation the cold water supply valve

must be opened.

IMPORTANT!

Water can start to drip from the opening of safety valve

then heating process is going. It’s impossible to avoid

leakage of water and you can’t prevent this! Locking

of valve may cause rupture of the inner tank in case

of failure.

IMPORTANT!

“Optimum” position on the control panel corresponds

to the optimum water heating temperature of 58

+/-2°C, at which:

1. The user is less likely to get burned in case when the

outlet water temperature is incorrectly adjusted.

2. A sufficient amount of hot water is obtained after

mixing with cold water, at a lesser power energy

consumption.

3. Less scale is generated on the heating element and

internal surfaces of the water heater.
