10
Note: A dull blade can be sharpened! But a blade that
is worn, bent, cracked or otherwise damaged must be
replaced.
Removing the blade: See illustration A3
If you remove the blade to sharpen or replace it, you
must use a torque wrench and some heavy gloves to
protect your hands.
1. Loosen the blade bolt. Use a piece of wood to
prevent the blade from turning around.
2. Remove the bolt, washer, blade and blade holder
in that order
3. Sharpen or replace the blade.
4. Insert the blade holder, blade, washer and bolt in
that order.
5. Tighten the blade bolt with 50 Nm. Use a piece of
wood to prevent the blade from turning around.
Warning: A blade must be sharpened so it is in
100 % balance, otherwise it may cause vibrations that
could damage the engine. Damage to engine due to
faulty sharpening is not covered by warranty. We
therefore recommend letting a service center sharpen
the blade.
Spark plug
1. Remove the spark plug.
2. Brush off dirt from the spark plug.
3. Use a spark plug wrench to loosen the spark plug.
4. Check the insulation is intact.
5. Clean the spark plug with a wire brush.
6. Measure the electrode, taking care not to damage
the electrode.
7. The distance should be: 0.7 to 0.8 mm
8. If the spark plug is undamaged refit or replace.
Art. no. 40-11294
9. Reattach the spark plug.
Storage and maintenance
Maintain your lawnmower: Check all bolts, screws,
nuts and deck. Dismount the blade and the belt plastic
cover for regular cleaning. Always make sure that the
blade is sharp. It’s a good idea to take your lawn mower
to an annual service check with your authorized service
dealer. See your nearest service center at
www.texas.dk.
Storage: After use the lawnmower kept in a dry and
clean room. Clean the machine after every use. Grass
and dirt must be removed from the underside of the
deck. By tipping the mower (for cleaning) is
recommended to tilt the front up (max. 45 degrees). If
you tilt it sideways, the carburetor and air filter always
face upwards, since oil may run out and destroy the
engine. Be aware that removing the spark plug before
the mower maintenance.
Winter storage: Empty the fuel tank and let the engine
run until the gasoline in the carburetor is used up. Spark
plug removed. Remove the spark plug and add a
teaspoon of oil (engine oil) in the hole. Pull the starter to
distribute oil. Mount the spark plug, but not the spark
plug cap. Change oil as described in the section above.
Spray silicone lubrication into the cables and move
them.
Finally, clean the mower thoroughly. Dip a cloth in oil
and luricate metal parts to prevent rust.
Warranty terms and conditions
The warranty period is 2 years for private end users in
EU countries.
Products sold for commercial use, only have a warranty
period of 1 year.
The warranty covers material and/or fabrication faults.
Restrictions and requirements
Normal wear and replacement of wearing parts are
NOT covered by the warranty.
Wearing parts, which are NOT covered for more than
12 months:
• Blades
• Cables
• Belts
• Fuses
• Switches
• Membranes/gaskets
• Spark plugs
• Engine liquids (oil, gasoline)
• Starter cords
• Filters
• Battery: If the battery is not stored correct (frost-
free and recharged every 3 months), the durability
is only guaranteed for 6 months.
If you start the engine without adding oil, it will be
damaged and cannot be repaired and therefore not
covered by the warranty.
The warranty does NOT cover damages/faults
caused by:
• Lack of service and maintenance
• Structural changes
• Exposure to unusual external conditions
• Damages to the bodywork, deck, handles, panels
etc.
• If the machine has been improperly used or
overloaded
• Wrong use of oil, gasoline or other liquid types,
which are not recommended in this user manual
• Bad or dirty gasoline, which results in
contamination of the fuel system
• Use of unoriginal spare parts.
• Other conditions where Texas cannot be held
responsible.
Whether a case is a warranty claim or not is
determined in each case by an authorized service
center.
Your receipt is your warranty note, why it should
always be kept safe.
REMEMBER: The purchase of spare parts as well as
any request for warranty repair, art. number (e.g.
900665XX), year and serial number should always be
informed. It can be found on the CE-label located on
the rearpart of the cutting deck behind the engine!
* We reserve the right to change the conditions and
accept no liability for any misprints
