Box Contents

Figure 1.

1. 1. Machine

2. 2. Operating manual and motor instructions

The lawn spiker is almost ready for use. Only the handlebar needs to be fitted.

Fit the bottom handlebar using the accompanying bolts. Figure 6.

Fit the top handlebar, unfold the handlebar and secure it in the required position with the

grips. See figure 2, c.

Use

Before use, follow the instructions for readying the motor in the

motor instruction manual.

Before using the machine, remove all foreign objects from the vicinity. Stones, glass,

branches and similar items can damage the machine. Also check that all bolts are

tightened.

Control oil levels before starting the motor.

Start:

Set the gas handle to choker / full gas, figure 2,a.

Follow motor start instructions.

Stop:

Set the gas handle to minimum gas, figure 2,a.

Follow motor stop instructions.

The clutch grip on the handle is used to activate the rotating blades under the machine. It

is important that the clutch allows for connection under operation, i.e. the clutch trigger is

to be held tight up against the handle.

Figure 2, b.

The rotating blades disengage automatically when the trigger is released.

Working depth can be adjusted using the handle on the right hand side of the machine,

(figure 3, b).

The machine can be lifted to its transport position by using the handle on the right hand

side of the machine, (figure 4, a).

Under Operation

The lawn spiker is used to loosen moss, etc. from the lawn. The machine’s blades rotate in

the direction of travel, thereby helping to propel the machine forward.

Start the motor and lower the machine to the ”work” position using the handle on the right

hand side of the machine. Activate the clutch trigger and engage the motor fully. Move the

lawn spiker forwards and backwards across the lawn. After the first aeration remove any

lose moss from the lawn. In the event that there is still moss in the lawn, aerate again at an

angle of 90 degrees to the previous aeration.
