Notebook PC User Manual

Display (Monitor) Output

The 15-pin D-sub monitor port supports a standard VGA-

compatible device such as a monitor or projector to allow

viewing on a larger external display.

LAN Port

The RJ-45 LAN port with eight pins is larger than the RJ-11

modem port and supports a standard Ethernet cable for

connection to a local network. The built-in connector allows

convenient use without additional adapters.

HDMI

HDMI Port

HDMI (High-Deﬁnition Multimedia Interface) is an

uncompressed all-digital audio/video interface between

any audio/video source, such as a set-top box, DVD player,

and A/V receiver and an audio and/or video monitor, such

as a digital television (DTV). Supports standard, enhanced,

or high-deﬁnition video, plus multi-channel digital audio

on a single cable. It transmits all ATSC HDTV standards and

supports 8-channel digital audio, with bandwidth to spare

to accommodate future enhancements or requirements.

ExpressCard Slot

One 26pin Express card slot is available to support one

ExpressCard/34mm expansion card. This new interface

is faster by using a serial bus supporting USB 2.0 and PCI

Express instead of the slower parallel bus used in the PC

card slot. (Not compatible with previous PCMCIA cards.)

USB Port (2.0/1.1)

Wireless Switch

Enables or disables the built-in wireless LAN and Bluetooth

(selected models). When enabled, the wireless status

indicator will light. Windows software settings are necessary

before use.
