Инструкция по эксплуатации Страница: 71

Sony SLV-685HF Инструкция по эксплуатации онлайн [71/71] 27897

Additional Information

SONY SLV-685HF (E) 3-859-040-11 (1)

Содержание

Operating instructions 1
Owner s record 1
Slv 685hf 1
Sony slv 685hf e 3 859 040 11 1 1
Video cassette recorder 1
Caution 2
For customers in the usa caution 2
Information 2
Installing 2
Introduction 2
Precautions 2
Safety 2
Sony slv 685hf e 3 859 040 11 1 2
To prevent fire or shock hazard do not expose the unit to rain or moisture 2
Warning 2
Additional information 3
Additional operations 3
Basic operations 3
Getting started 3
Table of contents 3
Step 1 4
Unpacking 4
Inserting the batteries 5
Setting up the remote commander 5
Step 2 5
Using the remote commander 5
Code numbers of controllable tvs if more than one code number is listed try entering them one at a time until you find the one that works with your tv 6
Controlling other tvs with the remote commander 6
Hold down power and enter your tv s code number s using the number buttons then release power 6
Now you can use the power vol ch and tv vtr buttons to control your tv you can also use the buttons marked with a dot to control a sony tv to control the vcr reset tv vtr to vtr 6
Set tv vtr at the top of the remote commander to tv 6
Sony slv 685hf e 3 859 040 11 1 6
Step 2 setting up the remote commander continued 6
The remote commander is preprogrammed to control non sony tvs if your tv is listed in the table below set the appropriate manufacturer s code number 6
Hookups 7
Selecting the best hookup option 7
Step 3 7
A use this hookup if your tv has stereo jacks 8
Audio video a v hookup 8
Audio video cable supplied 8
B use this hookup if your tv doesn t have stereo jacks 8
Getting started 8
If you re not planning to use your vcr to record programs you re finished setting up the vcr after you ve made the connections shown on this page if you want to record off air or off your cable tv system complete these connections first and then go to the following pages for antenna or cable hookups 8
If your tv has audio video a v input jacks you will get a better picture and sound if you hook up your vcr using these connections in addition for a true home theater experience you should connect the audio outputs of your vcr or tv to your stereo system if your tv doesn t have a v inputs see the following pages for antenna or cable hookups 8
Note to play a tape in stereo you must use the a v connection 8
Pages 8 and 9 8
Sony slv 685hf e 3 859 040 11 1 8
Step 3 hookups continued 8
Strereo receiver 8
Video cable not supplied audio cable not supplied 8
Getting started 9
Sony slv 685hf e 3 859 040 11 1 9
Hookup 1 10
Pages 10 to 12 10
Recommended use you should use this hookup if you have a cable box especially if your cable system scrambles all or most channels this hookup allows the vcr s cable box control feature to control the channel on the cable box simplifying the recording process a list of compatible cable boxes is on page 31 10
Sony slv 685hf e 3 859 040 11 1 10
Step 3 hookups continued 10
Using cable box control 10
What you can do with this hookup record any channel using the vcr s cable box control feature to select channels on the cable box 10
What you can t do record with the cable box turned off record one channel while watching another channel 10
For details see page 61 if you made a v connections from page 8 you can skip this step 11
Getting started 11
Hookup 1 vcr setup 11
Press easy set up on the vcr 11
Set the rf unit switch to ch 3 or ch 4 whichever channel is not used in your area if both are used set the switch to either channel 11
Sony slv 685hf e 3 859 040 11 1 11
Turn on your cable box 11
Find the vcr plus channel listing in your program guide for details see page 39 12
Hookup 1 vcr plus channel setup 12
If the channels in the program guide are different from the channels that you actually use on your tv set the channels that are different as follows for details see page 40 12
Sony slv 685hf e 3 859 040 11 1 12
Step 3 hookups continued 12
Getting started 13
Hookup 2 13
No cable box or compatible cable box with only a few scrambled channels 13
Pages 13 to 15 13
Recommended use use this hookup if you do not have a cable box also use this hookup if your cable company cannot supply a cable box that is compatible with the vcr s cable box control feature and your cable system scrambles only a few channels 13
Sony slv 685hf e 3 859 040 11 1 13
What you can do with this hookup record any unscrambled channel by selecting the channel on the vcr 13
What you can t do record scrambled channels that require a cable box 13
For details see page 61 if you made a v connections from page 8 you can skip this step 14
Hookup 2 vcr setup 14
Press easy set up on the vcr 14
Set the rf unit switch to ch 3 or ch 4 whichever channel is not used in your area if both are used set the switch to either channel 14
Sony slv 685hf e 3 859 040 11 1 14
Step 3 hookups continued 14
Find the vcr plus channel listing in your program guide for details see page 39 15
Getting started 15
Hookup 2 vcr plus channel setup 15
If the channels in the program guide are different from the channels that you actually use on your tv set the channels that are different as follows for details see page 40 15
Sony slv 685hf e 3 859 040 11 1 15
A use this hookup if you re using vhf uhf antenna you get channels 2 13 and channels 14 and higher uhf only antenna you get channels 14 and higher separate vhf and uhf antennas 16
Antenna hookup 16
B use this hookup if you re using a vhf only antenna you get channels 2 13 only 16
Hookup 3 16
Make the following connections if you re using an antenna if you don t have cable tv 16
Pages 16 to 18 16
Sony slv 685hf e 3 859 040 11 1 16
Step 3 hookups continued 16
For details see page 61 if you made a v connections from page 8 you can skip this step 17
Getting started 17
Hookup 3 vcr setup 17
Press easy set up on the vcr 17
Set the rf unit switch to ch 3 or ch 4 whichever channel is not used in your area if both are used set the switch to either channel 17
Sony slv 685hf e 3 859 040 11 1 17
Find the vcr plus channel listing in your program guide for details see page 39 18
Hookup 3 vcr plus channel setup 18
If the channels in the program guide are different from the channels that you actually use on your tv set the channels that are different as follows for details see page 40 18
Sony slv 685hf e 3 859 040 11 1 18
Step 3 hookups continued 18
Getting started 19
Hookup 4 19
Incompatible cable box with many scrambled channels 19
Pages 19 to 21 19
Recommended use this hookup if your cable company cannot supply a cable box that is compatible with the vcr s cable box control feature and your cable system scrambles all or most channels 19
Sony slv 685hf e 3 859 040 11 1 19
What you can do with this hookup record any channel by selecting the channel on the cable box 19
What you can t do record with the cable box turned off record one channel while watching another channel select channels directly on the vcr 19
For details see page 61 if you made a v connections from page 8 you can skip this step 20
Hookup 4 vcr setup 20
Press easy set up on the vcr 20
Set the rf unit switch to ch 3 or ch 4 whichever channel is not used in your area if both are used set the switch to either channel 20
Sony slv 685hf e 3 859 040 11 1 20
Step 3 hookups continued 20
Turn on your cable box 20
Hookup 4 21
Vcr plus channel setup 21
Dss digital satellite system receiver 22
Hookup 5 22
Pages 22 and 23 22
Recommended use use this hookup if you have a dss receiver it allows the vcr s cable box control feature to control the channel on the dss receiver simplifying the recording process a list of compatible dss receivers is on page 32 dss digital satellite system is a satellite broadcast that provides superior digital quality video and crisp digital quality audio a variety of program packages are available through your program providers it also has program guides that are sorted by program categories 22
Sony slv 685hf e 3 859 040 11 1 22
Step 3 hookups continued 22
What you can do with this hookup record any channels using the vcr s cable box control feature to select channels on the dss receiver 22
What you can t do record with the dss receiver turned off record any channels from cable or an antenna to record channels from cable or an antenna turn off the cable box control feature use a cable box record programs with vcr plus 22
For details see page 61 if you made a v connections from page 8 you can skip this step 23
Getting started 23
Hookup 5 vcr setup 23
Press easy set up on the vcr 23
Set the rf unit switch to ch 3 or ch 4 whichever channel is not used in your area if both are used set the switch to either channel 23
Sony slv 685hf e 3 859 040 11 1 23
Turn on your dss receiver 23
Hookup 6 24
Incompatible cable box with only a few scrambled channels using an a b switch 24
Pages 24 to 27 24
Recommended use by using an a b switch not supplied this hookup allows you to record both scrambled and unscrambled channels conveniently 24
Sony slv 685hf e 3 859 040 11 1 24
Step 3 hookups continued 24
What you can do with this hookup record any unscrambled channel by selecting the channel directly on the vcr the a b switch is set to a record any scrambled channel by selecting the channel on the cable box the a b switch is set to b 24
What you can t do record one scrambled channel while watching another channel the a b switch is set to b 24
For details see page 61 if you made a v connections from page 8 you can skip this step 25
Getting started 25
Hookup 6 vcr setup 25
Press easy set up on the vcr 25
Set the a b switch to a 25
Set the rf unit switch to ch 3 or ch 4 whichever channel is not used in your area if both are used set the switch to either channel 25
Sony slv 685hf e 3 859 040 11 1 25
Cable box output channel 26
Enter the cable box output channel 26
Getting started 26
Preset the cable box output channel usually 2 3 or 4 for details see page 37 26
Press menu and select tuner preset 26
Set manual set to add and press execute 26
Sony slv 685hf e 3 859 040 11 1 26
Step 3 hookups continued 26
Find the vcr plus channel listing in your program guide for details see page 39 27
For scrambled channels enter all the scrambled channels you want to record and the cable box output channel usually 2 3 or 4 for details see page 40 27
For unscrambled channels if the channels in the program guide are different from the channels that you actually use on your tv set the channels that are different as follows for details see page 40 27
Getting started 27
Hookup 6 vcr plus channel setup 27
Sony slv 685hf e 3 859 040 11 1 27
Selecting a language 28
Setting the clock 29
Setting up cable box control 30
Skip this section if you are using hookup 2 3 4 or 6 30
Cable box and dss receiver brand and the corresponding code numbers if more than one code number is listed try entering them one by one until you come to the correct code for your equipment 31
Cable box brand 31
Code numbers 31
Continued 31
Find your cable box dss receiver code number from the chart below 31
Getting started 31
If you want to control a cable box press cursor to select the output channel for the cable box then press execute 31
If you want to control a dss receiver select line then press execute 31
Press the number buttons to enter the cable box dss receiver code number then press cursor 31
Sony slv 685hf e 3 859 040 11 1 31
Cable box brand 32
Code numbers 32
Dss receiver brand 32
Getting started 32
Setting up cable box control continued 32
Sony slv 685hf e 3 859 040 11 1 32
Setting up cable box control continued 34
Presetting all receivable channels automatically 35
Presetting channels 35
Skip this section if you are using cable box dss receiver control 35
All receivable channels are preset in numerical sequence when no more receivable channels can be found presetting stops and the picture from the lowest numbered channel is displayed on the tv screen 36
Getting started 36
Presetting channels continued 36
Press cursor to set antenna cable to ant 36
Press cursor to set antenna cable to cable 36
Sony slv 685hf e 3 859 040 11 1 36
To preset cable tv channels 36
To preset vhf and uhf channels 36
To select auto preset then press execute 36
Presetting disabling channels manually 37
If the picture is not clear 38
Normally the auto fine tuning aft function automatically tunes in channels clearly if however the picture of a channel is not clear you can also use the manual tuning function 38
Note that the aft setting switches to off 38
Presetting channels continued 38
Press cursor to adjust to a clearer picture then press execute 38
Press menu and select tuner preset then press execute 38
Press the number buttons to select the channel you want to fine tune then press enter 38
Sony slv 685hf e 3 859 040 11 1 38
The fine tuning meter appears 38
To select fine tuning 38
For each channel your vcr receives use the channel line up chart to check that the channel numbers match for example if hbo is listed in the channel line up chart on channel 33 and your vcr receives hbo on channel 5 you need to coordinate these numbers using the following procedure for channels in which the numbers are the same you can skip this procedure 39
Getting started 39
How to set up your vcr setting up your vcr involves coordinating the tv channel number the number you turn to on your tv or vcr to watch a program with the guide channel the number that s assigned to that channel in your program guide to get the guide channel numbers find the channel line up chart in the program guide for your area that features vcr pluscodes it usually looks like the example to the right 39
How vcr plus works whenever you want to record a tv program all you need to do is look up the program s pluscode a number assigned to each program that s published in the tv section of most newspapers cable tv listings and even tv guide magazine then just enter the pluscode of the program you want and the vcr is automatically programmed to record that show it s that simple 39
Sample 39
Setting up vcr plus 39
Sony slv 685hf e 3 859 040 11 1 39
Enter the channel number assigned in the program guide and press enter 40
If you made hookup 1 or 3 enter the actual number on your tv and vcr and press enter 40
If you made hookup 2 enter the cable output channel usually 2 3 or 4 and press enter 40
If you made hookup 4 enter the actual number on your tv and vcr for an unscrambled channel and press enter for a scrambled channel enter the cable box output channel usually 2 3 or 4 and press enter 40
Setting up vcr plus continued 40
Sony slv 685hf e 3 859 040 11 1 40
To move the cursor z to set vcr plus channels and press execute 40
Getting started 41
Repeat steps 2 and 3 for each channel whose numbers don t match 41
Sony slv 685hf e 3 859 040 11 1 41
When you have set all channels press execute to confirm your channel settings 41
When you ve finished press menu to exit 41
Insert a tape 42
Playing a tape 42
Sony slv 685hf e 3 859 040 11 1 42
The vcr turns on and starts playing automatically if you insert a tape with its safety tab removed 42
Turn on your tv and set it to the video channel 42
Additional tasks 43
Basic operations 43
Press play 43
Press smart cue again when you find the scene you want to watch the vcr stops searching rewinds a few seconds then resumes normal playback 43
Press smart cue during playback of the scene you want to skip the vcr starts searching 43
Sony slv 685hf e 3 859 040 11 1 43
To display the counter on the tv screen press display 43
To skip playback you can skip a portion of playback you don t want to watch such as a commercial and restart playback by pressing a single button 43
To use the time counter at the point on the tape that you want to find later press counter reset the counter in the display window resets to 0h00m00s search for the point afterwards by referring to the counter 43
When the tape reaches the end it will rewind automatically 43
Insert a tape with its safety tab in place 44
Recording tv programs 44
Sony slv 685hf e 3 859 040 11 1 44
To record from a cable box turn it on 44
Turn on your tv and set it to the video channel 44
If the tv is connected to the vcr s line out jacks set the tv to tv input if not skip this step 46
Press tv vtr to turn off the vtr indicator in the display window 46
Recording tv programs continued 46
Select another channel on the tv 46
Sony slv 685hf e 3 859 040 11 1 46
To save a recording to prevent accidental erasure break off the safety tab as illustrated to record on a tape again cover the tab hole with adhesive tape 46
To watch another tv program while recording 46
Recording tv programs using vcr plus 47
Basic operations 48
Everyday monday to friday 48
If you make a mistake press timer clear and re enter the correct number 48
Once a week 48
Only once 48
Press power to turn off the vcr 48
Press tape speed to select sp or ep 48
Press the number buttons to enter the program s pluscode 48
Recording tv programs using vcr plus continued 48
Select 48
Select once daily or weekly by using cursor then press set 48
Sony slv 685hf e 3 859 040 11 1 48
The date start and stop times channel number and tape speed appear on the tv screen if the information is not correct press timer clear to cancel the setting 48
The timer indicator on the vcr lights up and the vcr stands by for recording when using a cable box leave it on 48
To enter another setting repeat steps 1 to 4 48
To record 48
To stop recording to stop the vcr while recording press p stop 48
Weekly 48
Before you start check that the vcr clock is set to the correct time turn on your tv and set it to the video channel when using a cable box turn it on insert a tape with its safety tab in place make sure the tape is longer than the total recording time 50
If vcr plus is not available in your area follow the instructions below to set the timer to record programs 50
Press menu and select timer set check then press execute 50
Setting the timer manually 50
Sony slv 685hf e 3 859 040 11 1 50
Playing searching at various speeds 52
Sony slv 685hf e 3 859 040 11 1 52
To resume normal playback press play 52
Recording tv programs using the quick timer 53
Using the quick timer during stop mode 53
Before you start turn on your tv and set it to the video channel 54
Checking changing canceling timer settings 54
If any timer settings remain turn off the vcr to return to recording standby 54
If you do not need to change the settings press execute then turn off the vcr to return to recording standby 54
If you want to change a setting go on to the next step 54
Press execute 54
Press menu and select timer set check 54
Press power to turn on the vcr 54
Sony slv 685hf e 3 859 040 11 1 54
To cancel the setting press timer clear 54
To reset it then press cursor repeatedly until the cursor z appears at the beginning of the line 54
To select the setting you want to change or cancel 54
When the timer settings overlap the program that starts first has priority and the second program starts recording only after the first program has finished if the programs start at the same time the program listed first in the menu has priority 54
Recording bilingual programs 55
Recording stereo and bilingual programs 55
Recording stereo programs 55
Selecting the sound while playing 55
How sound is recorded on a video tape 56
Recording stereo and bilingual programs continued 56
Sony slv 685hf e 3 859 040 11 1 56
The vcr records sound onto two separate tracks hi fi audio is recorded onto the main track along with the picture monaural sound is recorded onto the normal audio track along the edge of the tape 56
About adaptive picture control apc 57
Adjusting the picture 57
Adjusting the tracking 57
Changing menu options 58
Menu choices initial settings are indicated in bold print 58
Press execute to return to the original screen 58
Press menu and select advanced options 58
Sony slv 685hf e 3 859 040 11 1 58
To select the option to change then press cursor to change the setting 58
Connect line 2 in audio on this vcr to the audio output jacks on the stereo system using the rk c510ks audio cable not supplied 59
Editing with another vcr 59
How to hook up to a stereo system 59
How to hook up to record on this vcr 59
Sony slv 685hf e 3 859 040 11 1 59
Editing with another vcr continued 60
Operation when recording on this vcr 60
General setup information 61
Setting the rf unit 61
Attaching a uhf vhf band mixer 62
Attaching the external antenna connector 62
General setup information continued 62
Sony slv 685hf e 3 859 040 11 1 63
Symptoms caused by contaminated video heads 63
Troubleshooting 63
Sony slv 685hf e 3 859 040 11 1 64
Troubleshooting continued 64
Additional information 65
General 65
Inputs and outputs 65
Sony slv 685hf e 3 859 040 11 1 65
Specifications 65
Supplied accessories 65
System 65
Timer section 65
Tuner section 65
Front panel 66
Index to parts and controls 66
Display window 67
Rear panel 67
Index to parts and controls continued 68
Remote commander 68
H i j k 69
Sony slv 685hf e 3 859 040 11 1 69
V w x y z 69
Hookup 1 70
Hookup 2 70
Hookup 3 70
Hookup 4 70
Sony slv 685hf e 3 859 040 11 1 70
Uick reference to using the vcr 70
