12. Children should be supervised

to ensure that they do not play with

the appliance.

13. Service life – 4 years.

Instruction for use

1. Using warm water and washing up

liquid, wash all the removable parts

and the inside of the water tank, rinse

and dry.

2. Place the base unit on a stable

surface, put the turbo ring around the

heating element (the largest side on

the bottom).

3. Pour the fresh water directly into

the water tank up to the maximum

level.

4. Рut the food on the center of base.

5. Place the baskets on the top of the

juice collector, and put the lid on.

6. Plug in and set the time for

recommended cooking times (see

table of cooking times),the indicator

light on and steam cooking has begun.

7. Check the water level by looking

the exterior water level indicator, if

necessary, add water from the side of

juice collector during cooking.

8. The switch off automatically, timer

rings and the indicator light off.

9. You can reheat the food , carefully

if there is any more water.

10. Remove the lid, place the

basket(s) on the plate.

11. Unplug the appliance, let it cool

completely before cleaning.

Electro-panel operation

1. Put though the power supply,

you can see the display showing the

time as .

(1) Press the ‘PROG’ and

buttons at the same time, the buzzer

tweets when loosing the buttons.

(2) Increasing 10 minutes or

decreasing 1 minute per each press on

‘+’ button and ‘-’ button accordingly.

(3) Adjust the clock to the current

time, then ending the whole process

by press ‘PROG’ button.

2. Immediate steam mode

(1) Push the button under the

clock mode until the display shows

(2) Setting the steaming time by

pressing ‘+’ or ‘-’ buttons, increasing

or decreasing 5 minutes each press.

Press any button and stop the setting

procedure.

(3) The buzzer tweets two seconds

without pressing any button after the

steaming time is set. The red indicate

light brightened at the mean time,

that means the start of steaming, and

the clock starts to count the time.

(4) When setting the time as 0, the

electric timer will return to clock mode

automatically. The maximum steam

time is 90 minutes.

(5) When in steaming, you can press

‘+’ or ‘-’ button adjust the steaming

time. Press button to stop

steaming and return back to clock

mode.

3. Timing steam mode

(1) Press PROG under the mode of

Clock, there shows the time and PROG

on the display .

(2) Booking the time by pressing ‘+’

and ‘-’ buttons, increasing or

decreasing 10 minutes each time.

(3) Press ‘PROG’ button until the

display shows 45. Then press ‘+’ and

‘-’ to adjust the steaming time.

(4) Press ‘PROG’ button again, the

display shows the time and PROG,

which means entering into the timing

steam mode. When it comes into the

booking time, the buzzer tweets and

the red light lights, and the steamer

starts to steam the food according to

the set time.

(5) If you want to cancel the timing

steam mode, just press the PROG

button, it return back to clock mode.

4. When the steaming is finished, it

comes into the holding mode directly.

The display shows the time and the

holding symbol and the green light

lights .

Holding mode means warming for 2

minutes per 8 minutes after it stops

steaming.

Press button to cancel the

holding mode, and it returns back to

clock mode.

Cleaning and maintenance

1. Empty the water tank and clean it

with a damp cloth.

2. All the other removable parts can

be put in the dishwasher.

3. Descale the appliance every 8

times.

4. Position the turbo ring upside

down around the heating element (the

largest side on the upper). Fill the

water tank with cold water up to

“MAX” level, fill the inside of the turbo

ring with white vinegar to the same

level. Do not heat up (to avoid the

descaling odor). Leave overnight to

descale. Rinse out the inside of water

tank with warm water several times.

5. Stack the baskets one to the

other following No.1 into No.2, then

together into No.3. Put the rice bowl

into the Steamer basket No.1. At last

place the baskets on the juice collector

and put lid over them all.

Technical Data:

Power: 800 W

Rated Voltage: 220-240 V

Rated Frequency: 50 Hz

Rated Current: 3.6 А

Set

FOOD STEAMER 1

INSTRUCTION MANUAL WITH

WARRANTY CARD 1

RICE BOWL 1

PACKAGЕ 1

ENVIRONMENT FRIENDLY

DISPOSAL

You can help protect the

environment!

Please remember to

respect the local

regulations: hand in the

non-working electrical

equipments to an

appropriate waste

disposal center.

The manufacturer reserves the

right to change the specification

and design of goods.

ПАРОВАРКА

Уважаемый покупатель!

Поздравляем Вас с

приобретением изделия

торговой марки “Saturn”.

Уверены, что наши изделия

будут верными и надежными

помощниками в Вашем

домашнем хозяйстве.

Не подвергайте устройство

резким перепадам температур.

Резкая смена температуры

(например, внесение устройства

с мороза в теплое помещение)

может вызвать конденсацию

влаги внутри устройства и

нарушить его работоспособность

при включении. Устройство

должно отстояться в теплом

помещении не менее 1,5 часов.

Ввод устройства в эксплуатацию

после транспортировки

производить не ранее, чем через

1,5 часа после внесения его в

помещение.

Внимательно прочитайте всю

инструкцию по эксплуатации!

Будьте осторожны - устройство

подаёт горячий пар!

Описание

1. Крышка

2. Контейнер для риса (1 л)

（в зависимости от модели）

3. Ярус No.3

4. Ярус No.2

5. Ярус No.1

6. Поддон для конденсата и сока

7. Съемное турбо-кольцо

8. Внутренний индикатор

максимального уровня воды

9. Нагревательный элемент

10. Резервуар для воды (1 час

непрерывного использования)
