Connecting your equipment03
20
En
Connecting an HDD/DVD recorder, VCR and other video components
This receiver has audio/video inputs and outputs suitable for connecting analog or digital video
recorders, including HDD/DVD recorders and VCRs.
• Only the signals that are input to the VIDEO IN terminal can be output from the VIDEO OUT
terminal.
• Audio signals that are input through the digital terminal will not be output from the analog
terminal.
Important
•
If the connection was made using
an
optical cable
, press
SIGNAL SEL
repeatedly
to select
O2
(see page 26).
Note
• If the video components and TV also has an
HDMI or a component video jacks, you can
connect this too. See Connecting using
HDMI on page 18 or Connecting your
component with no HDMI terminal on
page 19 for more on this.
PLAY
RL
DIGITAL
AUDIO OUT
ANALOG AUDIO OUT
RL
ANALOG AUDIO IN
OPTICAL
VIDEO OUT
VIDEO IN
REC
AUDIO
AUDIO
DIGITAL
COMPONENT VIDEO
BD/TVD MULTI CH IN
BD/TV IN
HDMI
ANTENNA
AM
LOOP
FRONT
L
R
L
R
CENTERSURROUND
COAXIAL
(CD)
IN 1
1
-
2
(BD/TV)
IN 1
(DVD/SAT)
IN 2
OPTICAL
ASSIGNABLE
IR
ASSIGNABLE
1
-
2
ASSIGNABLE
OUT
OUT
MONITOR
YP
B
P
R
IN
ZONE2 OUT
MONITOR OUT BD/DVD IN DVD/SAT IN
SUBWOOFER
PRE OUT
L R
DVR/VCR
DVD/SAT
OUT
IN
DVR/VCR VIDEO
L
R
OUT
DVD/SAT
IN
BD/TV
IN
OUT
IN IN
IN
CD-R/TAPE CD
SUBWOOFER
IN
(BD/TV)
IN 1
IN 2
L
R
DIGITAL
OUT
IN
DVR/VCR
OUT
IN
DVR/VCR VIDEO
COAXIAL
OPTICAL
(CD)
IN 1
(DVD/SAT)
IN 2
DVR, VCR, LD player, etc.
Select one
