D) If the door does not close satisfactory (does not revert or does not secure properly) you may proceed as follows:

E) In case that a service must take place in the compartment of the engine, note that it is necessary to be done by a

qualified technician and proceed as follows:

 Remove the metal grill panel from the appliance following the instructions in paragraph 9.

 Unscrew the two screws that hold the sliding engine base, which are located at the front, just behind the grill panel.

 Pull towards you the engine base without moving the appliance.

 Proceed to the service of the engine.

 After you have finished, repeat the steps in the inverse order so that your appliance gets back in operation.

F) If the feed cable is damaged, it must be replaced by the manufacturer or a qualified person from the service

department, or by similarly specialized personnel, in order to avoid danger.

Do not cause any damage to the cooling circuit by the intervention of unauthorized personnel. Advise the

manufacturer and assign such works only to specialized technicians.

NOTE: Our Company has an organized network of qualified technicians throughout Greece. For any maintenance

or operation problem, contact your retailer.

Keep this booklet as well as all documents provided with your appliance and read the guarantee terms carefully.

 Place a sharp object - such as a small screw driver, stabber,

nail etc - in one of the holes which are located at the top of

the torsion bar, which is located on the upper side of the door

under the top hinge.

 By applying resistance with the stabber, unscrew with the

screwdriver the kingpin which is screwed on the top of the

torsion bar (figure 9). ATTENTION, HOLD THE SHARP

OBJECT STEADY TO AVOID AN INJURY BECAUSE

THE SPRING IS UNDER TENSION.

 By using a sharp object, turn the top of the torsion bar

anticlockwise until you are able to screw promptly the

kingpin in the next hole. After you screw the kingpin remove

the sharp object.

 Examine if the door secures satisfactorily following the above

mentioned procedure. If not, repeat the above steps.

TOP OF

TORSION BAR

DOOR

SHARP

TOOL

CANOPY

KINGPIN

SCREW

DRIVER

HINGE

Figure 9
