e2 All Models Service Manual

Service

Manual

Exploded

Part Number Description

Qty

Per

Oven

Unit

2 2175164 3/32 X 3/4 SLIT PIN 1 EA 1 3 6

6 30Z0503 SWITCH ON/OFF ROCKER DPST 1 EA 1 3 6 1

15 P30Z1472 MAGNETRON 1 EA 1 3 6 1

16 30Z1473 MTR SPEED CONTROLLER e2 1 EA 1 3 6

18 30Z1477 e2 MICROSWITCH SHORT ARM 3 EA 3 9 18 3

18 x2 PSJ160 e2 DOOR MICROSWITCH KIT 1 EA 1 3 6

20 30Z1480 e2/e6 MAG HI LIMIT STAT 1 EA 1 3 6 1

21 P30Z5009 TOUCH SCREEN

34 31Z1252 BOLT M4 X 10 HEX HD (PARTITION PLATE) 18 EA 18 54 108

36 32Z7069 PERSONALITY MODULE e2

1 EA 1 3 6 1

37 32Z7072 PERSONALITY MODULE e2

1 EA 1 3 6 1

39 DJ0009 HORN COVER FRAME e2 1 EA 1 3 6

41 DJ0024 UNDER DOOR COVER ASSY 1 EA 1 3 6

42 DJ0063 DRIP PAN FINISHED e2 1 EA 1 3 6

52 DJ0100 e2 BASE SEAL 1 EA 1 3 6

53 DR0009 MERRYCHEF BADGE GUIDE 2 EA 2 6 12

54 DR0011 TOUCHSCREEN OVERLAY 1 EA 1 3 6 1

55 DR0021 HARMONISED SPEAKER 1 EA 1 3 6

56 DR0042 OVERHEAT SAFETY STAT 1 EA 1 3 6 1

57 DR0045 SPEAKER WIRE 1 EA 1 3 6

58 DR0049 MERRYCHEF BADGE SMALL 1 EA 1 3 6

59 DR0050 MERRYCHEF BADGE SEAL SM 1 EA 1 3 6

60 DR0051 MERRYCHEF BADGE SLIDER SM 1 EA 1 3 6

61 DV0370 LOWER IMPINGER HANDLE 1 EA 1 3 6

70 PSJ204 e2 STIRRER ASSY 1 EA 1 3 6

71 & 61 PSJ209 e2 JET PLATE ASSY 1 EA 1 3 6

72 PSR109 DIODE REPLACEMENT KIT 1 EA 1 3 6 1

74 PSJ226 OUTER DOOR SKIN ASSY e2 1 EA 1 3 6

76 SJ301 STEAM TUBE ASSY e2 1 EA 1 3 6

77 SJ310 GREASE FILTER ASSY e2 2 EA 2 6 12

78 PSJ313 DOOR GASKET 1 EA 1 3 6 1

81-83-84 PSJ152 e2 DOOR HINGE KIT 1 EA 1 3 6 1

82 PSJ153 e2 DOOR ASSY (COMPLETE) 1 EA 1 3 6

Not Shown 30Z1457 eikon SRB 1.25V FUSE 1 EA 1 3 6 1

Not Shown SJ318 e2 CAVITY INSULATION KIT V3 1 EA 1 3 6

H:\Copy of Merrychef\Parts\Service Kits\Parts Lists - Quarterly Updates\Merrychef eikon Parts Lists - All Models 2015 Service Manual (v2Sept2015)

Page 1 of 12

10/09/2015
