Merrychef Eikon E5 Список запасных частей на Merrychef Eikon 3E (англ.) онлайн [41/45] 278992

e5 All Mdls Service Manual Part

Service

Manual

Exploded

Part Number Description

Qty

Per

Oven

Unit

73 P11C0579 DOOR OUTER COVER ASSY 1 EA 1 3 6

75 P11C0593 STIRRER MOTOR ASSY 1 EA 1 3 6

79 - 81 PSR101 EIKON DOOR HINGE KIT (NOTE-1 BELOW) EA 0 0 0

76 PSR109 DIODE REPLACEMENT KIT 2 EA 2 6 12 2

80 - 82 PSR102 EIKON M/SWITCH BRACKET KIT EA 0 0 0

Not Shown 30Z1457 EIKON SRB 1.25A FUSE 1 EA 1 3 6 1

Not Shown 40C1394 STEAM VENT CAP 1 EA 1 3 6

Not Shown 41C0005 500 LOWER TRIM ASSY 1 EA 1 3 6

Not Shown DR0045 SPEAKER WIRE 1 EA 1 3 6

Not Numbered DX0146 SCREW CAT COVER 4 EA 4 12 24

74 P11C0606 HOT AIR MOTOR SERVICE KIT EU 1 EA 1 3 6

83 30Z1330 0.88uF 2500V CAPACITOR 2 EA 2 6 12 2

84 P30Z1413 230V 50Hz TRANSFORMER 2 EA 2 6 12

85 40C0864 SHELF SUPPORT CTM3 EUROPE 2 EA 2 6 12

Not Shown P11C0595 e5 CAT CONVERTOR ASSY 1 EA 1 3 6

Not Shown SR206 POWER SUPPLY LEAD GC 3P (EU) 1 EA 1 3 6

3 30Z0217 FUSE 1in 10A HRC 2 EA 2 6 12 2

4 30Z0231 FUSEHOLDER 1in (13A) 3 EA 3 9 18

6 30Z1207 FUSE 1in 3A HBC 1 EA 1 3 6 1

8 30Z1148 MOTOR START CAP 6uF 1 EA 1 3 6

86 790047 ELEMENT COVER PLATE (NON CAT) 1 EA 1 3 6

Not Shown SR206 POWER SUPPLY LEAD GC 3P (EU) 1 EA 1 3 6

3 30Z0217 FUSE 1in 10A HRC 2 EA 2 6 12 2

4 30Z0231 FUSEHOLDER 1in (13A) 3 EA 3 9 18

6 30Z1207 FUSE 1in 3A HBC 1 EA 1 3 6 1

8 30Z1148 MOTOR START CAP 6uF 1 EA 1 3 6

14 30Z1425 LV TRANSFORMER 1 EA 1 3 6 1

17 30Z1437 2.5uF STARTER CAP - MOTOR START 1 EA 1 3 6

74 P11C0606 HOT AIR MOTOR SERVICE KIT EU 1 EA 1 3 6

83 30Z1330 0.88uF 2500V CAPACITOR 2 EA 2 6 12 2

eikon e5 - 230V 50Hz UK/EU - Unique Parts

H:\Copy of Merrychef\Parts\Service Kits\Parts Lists - Quarterly Updates\Merrychef eikon Parts Lists - All Models 2015 Service Manual (v2Sept2015)

Page 2 of 6

07/09/2015

*All Prices Quoted Are At Merrychef Recommended UK List Price And Are Subject To Change.
