e2 All Models Service Manual

Service

Manual

Exploded

View

Part Number Description

Qty

Per

Oven

Unit

1-10

Ovens

11-50

Ovens

51-100

Ovens

Recommended

Service List

Merrychef eikon e2 Oven

Recommended Min Stock Holding & Service ListRecommended Parts List

eikon e2 230Volts 50Hz 20A - EU - Unique Parts

3 30Z0217 FUSE 1in 10A HRC 1 EA 1 3 6 1

4 30Z0231 FUSEHOLDER 1in (13A) 2 EA 2 6 12

5 30Z0394 FUSE 1in 7A HRC 1 EA 1 3 6 1

6 31Z1250 MAINS ON/OFF SWITCH COVER 1 EA 1 3 6

6 31Z1251 MAINS ON/OFF SWITCH BEZEL 1 EA 1 3 6

7 30Z1177 20 AMP LITTLEFUSE FLM020 2 EA 2 6 12 2

8 30Z1178 30A FUSE HOLDER 2 EA 2 6 12

11 30Z1482 e2 MAINS FILTER 20VT-1 1 EA 1 3 6

12 30Z1455 TRANSFORMER LV CLASS 2 1 EA 1 3 6 1

13 30Z1431 1.2uF 2500V CAPACITOR 1 EA 1 3 6 1

17 30Z1475 CABINET FAN e2 LRG 2 EA 2 6 12

17 30Z1542 e2 FAN MOTOR AC 4300 H 1 EA 1 3 6

19 SJ358 e2 CAVITY THERMOCOUPLE 1 EA 1 3 6 1

22 30Z5014 CONTROL PCB e2

SRB

VDE 1 EA 1 3 6 1

27 31Z0651 3-WAY TERMINAL BLOCK 2 EA 2 6 12

29 31Z1255 CABLE GLAND BLACK PG21 1 EA 1 3 6

30 31Z1256 NUT FOR CABLE GLAND PG21 1 EA 1 3 6

32 SJ371 ROBUST AIR FILTER EU 1 EA 1 3 6 1

43 SJ325 e2 LID ASSY EU 1 EA 1 3 6

64 DX0106 MAINS SUPPLY LEAD G (UL) 1 EA 1 3 6

65 P30Z1413 230V 50Hz TRANSFORMER 1 EA 1 3 6

75 SJ320 e2 BACK PANEL ASSY EU 1 EA 1 3 6

79 SJ314 SIDE COVER RHS ASSY e2 1 EA 1 3 6

80 SJ315 SIDE COVER LHS ASSY e2 1 EA 1 3 6

Not Numbered DJ0185 MAG FAN SHROUD MK2 1 EA 1 3 6

eikon e2 208/240Volts 60Hz 15A - USA - Unique Parts

86 30Z1439 RELAY 12V OMRON 1 EA 1 3 6 1

3 30Z1508 e2 FUSE 10A 1 1/4in 1 EA 1 3 6 1

4 30Z0285 FUSE HOLDER 1 1/4in 1 EA 1 3 6

8 30Z1505 e2 USA LARGE FUSE HOLDER 2 EA 2 6 12

11 30Z1479 e2 RFI FILTER 1 EA 1 3 6

12 30Z1455 TRANSFORMER LV CLASS 2 1 EA 1 3 6 1

13 30Z1501 0.91 uF HV CAP 2300V 1 EA 1 3 6 1

14 30Z1440 RELAY 240V OMRON 1 EA 1 3 6 1

17 30Z1475 CABINET FAN e2 LRG 2 EA 2 6 12

17 30Z1476 CABINET FAN e2 SML 1 EA 1 3 6

19 SJ358 e2 CAVITY THERMOCOUPLE 1 EA 1 3 6 1

22 30Z5010 CONTROL PCB e2

SRB

1 EA 1 3 6 1

28 31Z0661 e2 USA 2-WAY TERM BLOCK 1 EA 1 3 6

29 & 30 31Z1331 e2 US GLAND + NUT 1 EA 1 3 6

32 DJ0144 USA CARTRIDGE FILTER 1 EA 1 3 6 1

43 DJ0122 LID FINISHED e2 US 1 EA 1 3 6

64 DJ0139 e2D MAINS LEAD SP 15A 1 EA 1 3 6

66 P30Z1509 e2 TRANS 208-230V 60Hz 1 EA 1 3 6

75 DJ0123 BACK COVER FINISHED US 1 EA 1 3 6

79 SJ326 e2 SIDE COVER RH ASSY US 1 EA 1 3 6

80 SJ327 e2 SIDE COVER LH ASSY US 1 EA 1 3 6

Not Shown 30Z1474 e2 THERMAL TRIP 1 EA 1 3 6 1

Not Shown 30Z1526 e2 USA 15A FUSE 2 EA 2 6 12 1

Not Shown 31Z0527 SILASTIC RED TUBE 0 0 0

Not Shown 31Z1322 FAN GUARD LRG 1 EA 1 3 6

Not Shown 31Z1323 FAN GUARD SML 1 EA 1 3 6

Not Shown 31Z1324 e2 LEG 4 INCH 4 EA 4 12 24

Not Numbered DJ0141 REAR DUCT USA e2 1 EA 1 3 6

H:\Copy of Merrychef\Parts\Service Kits\Parts Lists - Quarterly Updates\Merrychef eikon Parts Lists - All Models 2015 Service Manual (v2Sept2015)

Page 4 of 12

10/09/2015

*All Prices Quoted Are At Merrychef Recommended UK List Price And Are Subject To Change.
