e2 All Models Service Manual
Service
Manual
Exploded
View
Part Number Description
Qty
Per
Oven
Unit
1-10
Ovens
11-50
Ovens
51-100
Ovens
Recommended
Service List
Merrychef eikon e2 Oven
Recommended Min Stock Holding & Service ListRecommended Parts List
eikon e2 208/240Volts 60Hz 15A Parent - USA - Unique Parts
86 30Z1439 RELAY 12V OMRON 1 EA 1 3 6 1
3 30Z1508 e2 FUSE 10A 1 1/4in 1 EA 1 3 6 1
4 30Z0285 FUSE HOLDER 1 1/4in 1 EA 1 3 6
8 30Z1505 e2 USA LARGE FUSE HOLDER 4 EA 4 12 24
11 30Z1479 e2 RFI FILTER 1 EA 1 3 6
12 30Z1455 TRANSFORMER LV CLASS 2 1 EA 1 3 6 1
13 30Z1501 0.91 uF HV CAP 2300V 1 EA 1 3 6 1
14 30Z1440 RELAY 240V OMRON 1 EA 1 3 6 1
17 30Z1475 CABINET FAN e2 LRG 2 EA 2 6 12
17 30Z1476 CABINET FAN e2 SML 1 EA 1 3 6
19 SJ358 e2 CAVITY THERMOCOUPLE 1 EA 1 3 6 1
22 30Z5010 CONTROL PCB e2
SRB
1 EA 1 3 6 1
28 31Z0661 e2 USA 2-WAY TERM BLOCK 1 EA 1 3 6
29 & 30 31Z1331 e2 US GLAND + NUT 1 EA 1 3 6
32 DJ0144 USA CARTRIDGE FILTER 1 EA 1 3 6 1
43 DJ0122 LID FINISHED e2 US 1 EA 1 3 6
64 DJ0140 e2P MAINS LEAD DF 30A 1 EA 1 3 6
66 P30Z1509 e2 TRANS 208-230V 60Hz 1 EA 1 3 6
75 DJ0123 BACK COVER FINISHED US 1 EA 1 3 6
79 SJ326 e2 SIDE COVER RH ASSY US 1 EA 1 3 6
80 SJ327 e2 SIDE COVER LH ASSY US 1 EA 1 3 6
Not Shown 30Z1474 e2 THERMAL TRIP 1 EA 1 3 6 1
Not Shown 30Z1494 e2 US DEPENDENDANT SOCKET 1 EA 1 3 6
Not Shown 30Z1526 e2 USA 15A FUSE 4 EA 4 12 24 1
Not Shown 31Z0527 SILASTIC RED TUBE 0 0 0
Not Shown 31Z0659 e2 USA TWIN WIRE LOOM 1 EA 1 3 6
Not Shown 31Z1322 FAN GUARD LRG 1 EA 1 3 6
Not Shown 31Z1323 FAN GUARD SML 1 EA 1 3 6
Not Shown 31Z1324 e2 LEG 4 INCH 4 EA 4 12 24
Not Numbered DJ0141 REAR DUCT USA e2 1 EA 1 3 6
eikon e2 208/240Volts 60Hz 20A - USA - Unique Parts
86 30Z1439 RELAY 12V OMRON 1 EA 1 3 6 1
3 30Z1508 e2 FUSE 10A 1 1/4in 1 EA 1 3 6 1
4 30Z0285 FUSE HOLDER 1 1/4in 1 EA 1 3 6
7 30Z1504 e2 USA FUSE HOLDER 1 EA 1 3 6
11 30Z1479 e2 RFI FILTER 1 EA 1 3 6
12 30Z1455 TRANSFORMER LV CLASS 2 1 EA 1 3 6 1
13 30Z1501 0.91 uF HV CAP 2300V 1 EA 1 3 6 1
17 30Z1475 CABINET FAN e2 LRG 2 EA 2 6 12
17 30Z1476 CABINET FAN e2 SML 1 EA 1 3 6
19 SJ358 e2 CAVITY THERMOCOUPLE 1 EA 1 3 6 1
22 30Z5010 CONTROL PCB e2
SRB
1 EA 1 3 6 1
28 31Z0661 e2 USA 2-WAY TERM BLOCK 1 EA 1 3 6
29 & 30 31Z1331 e2 US GLAND + NUT 1 EA 1 3 6
32 DJ0144 USA CARTRIDGE FILTER 1 EA 1 3 6 1
43 DJ0122 LID FINISHED e2 US 1 EA 1 3 6
64 DJ0138 e2 USA 20A MAINS LEAD 1 EA 1 3 6
66 P30Z1509 e2 TRANS 208-230V 60Hz 1 EA 1 3 6
75 DJ0123 BACK COVER FINISHED US 1 EA 1 3 6
79 SJ326 e2 SIDE COVER RH ASSY US 1 EA 1 3 6
80 SJ327 e2 SIDE COVER LH ASSY US 1 EA 1 3 6
Not Shown 30Z1474 e2 THERMAL TRIP 1 EA 1 3 6 1
Not Shown 30Z1527 e2 USA 20A FUSE 2 EA 2 6 12 1
Not Shown 31Z0527 SILASTIC RED TUBE 0 0 0
Not Shown 31Z1322 FAN GUARD LRG 1 EA 1 3 6
Not Shown 31Z1323 FAN GUARD SML 1 EA 1 3 6
Not Shown 31Z1324 e2 LEG 4 INCH 4 EA 4 12 24
Not Numbered DJ0141 REAR DUCT USA e2 1 EA 1 3 6
H:\Copy of Merrychef\Parts\Service Kits\Parts Lists - Quarterly Updates\Merrychef eikon Parts Lists - All Models 2015 Service Manual (v2Sept2015)
Page 5 of 12
10/09/2015
*All Prices Quoted Are At Merrychef Recommended UK List Price And Are Subject To Change.
