TALH / BFL _FL06_IT-EN Rev.01 11-2014 pag. 49
6 - INSTRUCTIONS
The entire set of equipment is controlled by an electronic circuit board powered by means of the ON/OFF master switch.
Use the controls located on the panel, together with the illuminated displays, to activate manual or automatic operations.
6.1 - PRELIMINARY CHECKS
Power the circuit board by turning the master switch to ON. When the equipment is idle the following settings can be made
(if the appliance is active, press Start (G) before proceeding).
Display (E) shows the Day, indicated as: 1=Monday, 2=Tuesday, …7=Sunday.
Display (D) shows current Time, expressed in hours and minutes.
When the Clock (H) button is held down for 3 seconds the current Day will begin to flash (E): use the UP and DOWN
arrows to set the correct day.
Press Clock (H) again to set the Hour and Minutes in the same way (D).
6.2 - MANUAL OPERATION
Manual mode comprises three separate stages of infinite duration: INSTRUCTIONS
- preservation
- proving
- holding
During operation a diagram (F) shows the activation of the different stages graphically.
When the master switch is ON, displays (D) and (E) show the current Time and Day respectively.
Press Start (G) to view the mode on the display (D). Use the UP and DOWN arrows to go from “AUTO” to “MAN” and
confirm with OK.
For 10 seconds the display (A) will flash, after which the manual preservation stage will start.
Press (P) or (Q) to go on to the proving or holding stage.
Preservation stage
During this stage the display (A) shows the temperature of the cabinet and displays (B) and (C) remain off. Press
Thermometer (I) to view the working set-point. The value flashes and can be accepted with OK or edited with the UP and
DOWN arrows before confirming with OK. (If OK is not pressed confirmation is automatic by time-out). The first three leds
are on (blue line on the graph (F)).
(For setting limits see par. 1.6)
Proving stage
During this stage the display (B) shows the temperature of the cabinet, display (C) the percentage of humidity measured
by the probe: display (A) is off. Press Thermometer (L) to view cabinet temperature set-point. The value flashes and can
be accepted with OK or edited with the UP and DOWN arrows before confirming with OK. (If OK is not pressed confirmation
is automatic by time-out).
In the same way press Humidity (N) to view/set the humidity set-point. The fourth, fifth and sixth leds are on (red line on
graph (F)).
(For setting limits see par. 1.6)
Holding stage
During this stage the display (B) shows the cabinet temperature; displays (E) and (C) are off. Press Thermometer (M) to
view the cabinet temperature set-point. The value flashes and can be accepted with OK or edited with the UP and DOWN
arrows before confirming with OK. (If OK is not pressed confirmation is automatic by time-out).
The last three leds are on (red line on graph (F)).
(For setting limits see par. 1.6)
