13
..
....
..are not suitable
are not suitableare not suitable
are not suitable:
::
:
- Crystal glass
- Steel items subject to rusting
- Wooden platters
- Items made from synthetic fibres
Recommendations for loading
Recommendations for loadingRecommendations for loading
Recommendations for loading
• Arrange sensitive, light tableware items such as glasses, coffee and tea cups in the upper basket.
• Place large items that are most difficult to clean in the lower basket.
• Make sure that the tableware is placed securely and cannot tip over.
• Place all items so, that the spray arms can rotate freely during rinsing.
• Arrange all items with openings facing down.
• Curved items, or ones with recesses, should be loaded aslant so that water can drain off.
• Make sure that glasses do not touch each other.
• Set the dishes and cutlery not into each other or covering each other.
• Arrange cutlery in the cutlery rack.
• Store long as well as sharp cutlery in the cutlery rack or horizontally in the dishwasher basket.
M
MM
Method
ethodethod
ethods for
s fors for
s for
loading n
loading nloading n
loading normal
ormal ormal
ormal d
dd
dishware
ishwareishware
ishware
Loading the upper basket
Loading the upper basketLoading the upper basket
Loading the upper basket
Loading the lower basket
Loading the lower basketLoading the lower basket
Loading the lower basket
On the upper basket only
small and medium items
should be loaded. Load e.g.
glasses, cups, saucers and
small bowls.
The basket is suitable because
of the particularly intense clean-
ing action of the lower spray
arm for heavily soiled dishes.
Load e.g. pots and plates.
1 Cups 3 Glasses 5 Bowl 7 Dessert dishes 9 Soup plates
2 Saucers 4 Bowl 6 Bowl 8 Dinner plates 10 Platter
C
CC
Cup shelves
up shelvesup shelves
up shelves P
PP
Plate holders
late holderslate holders
late holders
If necessary, fold the
cup shelves downwards
or remove them.
In order to create a better arrange-
ment for bulky dishes, the racks
can be folded.
Lift the racks slightly and fold them down.
Adjusting the upper basket
Adjusting the upper basketAdjusting the upper basket
Adjusting the upper basket
The height of the upper basket can be adjusted by placing the wheels on rails of different heights. This will
create more space for large items in the upper as well as in the lower basket.
• Pull out the basket guides.
• Remove the basket out of the guides.
• Depending on the desired setting, insert the upper or lower pair of wheels into
the guide; the left and right side should always be located at the same height.
