Содержание

Fm 170 300ake n fm 480 600ake n fm 480 600awke n fm 750 1000ake n fm 1200 1800alke n 1
Hoshizaki 1
Modular ice maker 1
Service manual 1
Contents 2
I specifications 1 dimensions specifications 5
Construction 43
Extruding head upper bearing housing lower bearing 50
Ii maintenance and cleaning instructions important 50
Mechanical seal 50
Air filter air cooled model only 51
Condenser air cooled model only 51
Gear motor 51
Control water valve 52
Caution 53
Cleaning of water system warning 53
Important 53
Iii technical information 1 water circuit and refrigerant circuit 55
Wiring diagram 60
Fm 300ake n fm 480ake n 89
C1 capacitor gm1 90
Cb controller board main 90
F fuse 3 5a 90
Fm 480awke n 90
Ob controller board operation 90
Ol circuit protector 20a 90
S3 operation switch 90
Tr transformer 90
X1 power relay control water valve on board 90
X2 power relay flush water valve on board 90
X3 power relay gear motor on board 90
X4 power relay compressor on board 90
X5 power relay gm drive 90
Fm 600ake n fm 600awke n 91
Icemaking mechanism 98
K chute bin control switch fm 750 1000 auxiliary code a 2 or earlier fm 1200 1800 auxiliary code a 3 or earlier the chute and bin control switch are caulked and combined ice formed in the evaporator casing passes through the spout chute and bin control switch and drops out of the unit bottom the chute is made of integrally molded hard pvc and soft pvc ice sliding down on the spout hits the soft material resulting in lower hitting sounds the bin control switch is an infrared photo sensor built in a plastic bracket the infrared photo sensor has a light emitting element and a light receiving element the sensor detects there is no ice when infrared rays from the light emitting element come into the light receiving element when ice comes between the two elements the sensor detects the bin is full and stops icemaking operation the unit resumes operation automatically when ice disappears from between the two elements if the plastic part of the bin control switch or the infrared sensor lens is 101
The ice detector is different for flake icemaker and nugget icemaker if incorrect detector is attached the bin control function will not work if the icemaking operation continues the abnormal stop switch trips and the unit stops with an error be sure to attach the proper ice detector the actuator is composed of two components bonded the letters c and f are stamped on the fitting part the type of icemaker can be distinguished by boss fitting position 103
Band moves and presses microswitch 104
Chute spout 104
Microswitch 104
N chute switch fm 170 300 480 600 auxiliary code d0 or earlier fm 750 1000 auxiliary code a 3 to d0 fm 1200 1800 auxiliary code a 4 tod0 the chute switch consists of a microswitch and a band securing the spout and chute when the bin control switch breaks down the band opens and presses the button on the microswitch contacts open to stop the icemaker error code el to restart the icemaker remove ice from the spout and chute and move the operation switch to the stop position then to the run position normal condition abnormal condition 104
O spout spout cover fm 300 480 600ake n fm 480 600awke n auxiliary code d 1 or later fm 750 1000ake n auxiliary code a 2 or earlier d 1 or later fm 1200 1800alke n auxiliary code a 3 or earlier d 1 or later the spout and spout cover are connected to the evaporator casing with a removable flange these are the passage to deliver ice formed inside the evaporator casing into the chute the spout is provided with a reed switch ant the spout cover with a magnet if the bin control switch goes wrong and fails to stop icemaking operation with the bin full ice pushes up the spout cover and the magnet gets away from the reed switch to stop the unit 104
Electric circuit 105
Operation board 107
Protectors 112
Error codes 113
Interlock errors 113
Non interlock errors 114
Performance data 115
10 20 30 40 116
B fm 170ake n 116
The horizontal axis shows the ambient temperature it refers to the data of at wt 10 10 21 15 32 21 40 35 116
10 20 30 40 131
The horizontal axis shows the ambient temperature it refers to the data of at wt 10 10 21 15 32 21 40 35 131
10 20 30 40 132
S fm 1800alke t fm 1800alke n 132
The horizontal axis shows the ambient temperature it refers to the data of at wt 10 10 21 15 32 21 40 35 132
Display error records by operating the operation board see iii 5 d displaying error log check for a possible cause and service the unit 133
Iv service diagnosis 133
No ice production 133
Low ice production 135
Others 135
V removal and replacement 1 service for refrigerant lines 137
Brazing danger 140
Compressor important 140
Warning 140
Drier important 141
Expansion valve important 142
Warning 142
Water regulating valve water cooled model only important 143
Evaporator assembly 144
Important 145
Warning 145
Warning 146
Control water valve 147
Flush water valve 147
Controller board important 148
