CLOCK RADIO WITH ALARM AND PROJECTOR

MODEL: VT-3508

1. POWER SELECTOR (AUTO/ON/OFF)

2. LED INDICATOR

3. AUTO MODE INDICATOR

4. SNOOZE BUTTON

5. ALARM SET/OFF

6. TIME SET BUTTON

7. SLEEP BUTTON

8. LOW/HIGH DIMMER SWITCH

9. HOUR BUTTON

10.MIN BUTTON

11.VOLUME DIAL

12.BAND SELECTOR (AM/FM)

13.TUNING DIAL

14.BACKUP BATTERY COMPARTMENT

15.FM-ANTENNA

16.POWER CORD

17.RADIO FREQUENCY SCALE

18.PROJECTION ON/OFF BUTTON

19.PROJECTOR

20.PROJECTOR TIME SET BUTTON

21.HOUR BUTTON

22.MIN BUTTON

23.FOCUS DIAL

24.ALARM RADIO/BUZZ SELECTOR

AC POWER SUPPLY

Before connecting, make sure that the electrical

supply voltage is compatible with the devices

voltage requirements.

CAUTION

 Remove the AC plug from the outlet if the device

will not be used for a long period of time.

 Do not attempt to repair this device yourself;

there are no user-serviceable parts inside.

 Do not allow water to splash or spill onto the

device in order to avoid fire and electric shock.

 Do not obstruct the natural ventilation of the

device; do not place it in closed bookshelves or

on shelves were there is not good ventilation.

 Do not place sources of open flames, like can-

dles, on the device.

 In case of malfunction, contact an authorized

service center.

CLOCK

 Open the battery compartment (14) and install

one 6F-22 type 9V battery (not included). The

battery is used to save information regarding the

current time and alarm settings in case of AC

power interruption.

 Set the AUTO/OFF/ON (1) selector to the Off

position and plug the power plug into the outlet;

the display will start to blink.

 To set the current time, press and hold the TIME

(6) button, then use the HOUR (10) and MIN (9)

buttons to set the current time.

THE CURRENT TIME ON THE CLOCK AND THE

PROJECTED TIME ARE SET SEPARATELY.

SETTING THE PROJECTED TIME

 To project the current time onto the wall, point

the projector away from itself and into a horizon-

tal position.

 Turn on the projector using the PROJECTION

ON/OFF (18) button; use the FOCUS (23) dial to

achieve a sharp image on the wall.

 To set the current time on the projector, press

and hold the TIME (20) button, then use the MIN

(22) and HOUR (21) buttons to set the current

time.

NOTE: THE PROJECTION DISTANCE OF THE

TIME IN A DARK ROOM IS FROM 0.9 TO 2. 7 m.

SETTING THE ALARM TIME

 Press and hold the ALARM (5) button; use the

HOUR (9) and MIN (10) buttons to set the

desired alarm time.

WAKING UP TO THE RADIO

 Set the alarm time as instructed above.

 Set the AUTO/OFF/ON (1) selector to the On

position.

 Tune the radio to the desired station and adjust

the volume.

 Set the ALARM RADIO/BUZZ (24) selector to

RADIO.

 Set the AUTO/ON/OFF (1) selector to AUTO.

The alarm will activate at the pre-set time and

will automatically turn off after 1 hour and 59

minutes.

WAKING UP TO BUZZER ALARM

 Set the alarm time as indicated above.

 Rotate the VOLUME/BUZZ (24) dial counter-

clockwise until it clicks in order to activate the

BUZZ alarm mode.

 Set the Auto/Off/On (1) selector to Auto. The

buzzer alarm will activate at the set alarm time.

TURNING OFF THE ALARM

 Press the ALARM SET/OFF (5) button to turn off

the alarm; the set alarm time remains saved for

use the next day.

 Set the AUTO/ON/OFF (1) selector to the OFF

position to turn off the alarm permanently.

SNOOZE MODE

 You can temporarily silence the alarm (buzzer or

radio) by pressing the Snooze (4) button; the

alarm will automatically activate again in 9 min-

utes.

ENGLISH
