45 CM

Important notices for the installation:

1. This appliance must be installed by a competent person and with particular attention to ventilation

2. The housing must be heat resistant to a temperature of 95 °C as per EEC directives.

3. The oven can be installed into a Standard 600 mm housing unit as shown in Figure-1, or in a tall housing unit

when built-in a column.

4. In both cases ventilation provisions must be made. Keep a gap at the back of the housing unit of 85 - 90 mm

depth.

5. Do not step-on, lean-on or rest heavy items on the open door, or maneuvers the oven by the door.

TECHNICAL FEATURES OF YOUR OVEN

Specifications 60 cm 45 cm

Outer width 595 mm 450 mm

Outer depth 610 mm 560 mm

Outer height 595 mm 595 mm

Inner width 460 mm 365 mm

Inner depth 400 mm 410 mm

Inner height 350 mm 355 mm

Lamp power 15 w 15 w

Thermostat 50 - 280

c 50 - 280

Bottom heating element 1200 w 1000 W

Top heating element 1000 w 800 W

Turbo heating element 2200 w 1800 W

Grill heating element 2000 w 1500 W

Supply voltage 220-240 V AC, 50-60 Hz
