Subwoofer

The Subwoofer Output is on the wire harness. (Refer to Wiring Diagram) This output is designed for

connecting up to 2 subwoofers to the unit. Follow the amplifier’s installation instructions. You can turn the

subwoofer on/off by pressing the icon in the main menu.

Rear view camera function

The rear view camera input is on the back of the unit. (refer to wiring diagram). This input (in yellow) is for

connecting backup camera for parking. You must connect the VCC wire (in purple-white color) to the reverse

gear switch in order to activate this video input mode when you switch the reverse gear of your car. Please

refer to the wiring diagram for more details.

Changeable backlight

Tap the CC.LED icon on the screen to access the RGB function. There are 9 colors to select: RED, GREEN,

BLUE, PURPLE, ORANGE, ICEBLUE, WHITE, CUSTOM and AUTO. When you select RED, the color of the LED

backlight will turn to red, and so for GREEN, BLUE, PURPLE, ORANGE, ICEBLUE, WHITE. When you select

CUSTOM, the parameter of color below will be activated. There are 3 parameters, namely R, G and B which

range from 0 to 100. When you select AUTO, the color of LED backlight will change in cycle among RED,

GREEN, BLUE, PURPLE, ORANGE, ICEBLUE, and WHITE.
