50
AXIS 216FD/FD-V/MFD/MFD-V - Troubleshooting
Emergency Recovery Procedure
If power or the network connection to the camera is lost during the upgrade, the process
fails and the unit becomes unresponsive. A flashing red Status LED indicates a failed
upgrade. To recover the unit, follow the steps below. The serial number is found on the
label attached to the bottom of the camera.
1. UNIX/Linux - From
the command line, type the following:
arp -s <IP address of camera> <serial number> temp
ping -s 408 <IP address of camera>
Windows - From a command/DOS prompt, type the following:
arp -s <IP address of camera> <serial number>
ping -l 408 -t <IP address of camera>
2. If the unit does not reply within a few seconds, restart it and wait for a reply.
Press CTRL+C to stop Ping.
3. Open a browser and type in the camera’s IP address. In the page that appears, use
the Browse button to select the upgrade file to use, for example, axis216fd.bin.
Then click the Load button to restart the upgrade process.
4. After the upgrade is complete (1-10 minutes), the unit automatically restarts and
shows a steady green on the Power and Status LEDs and flashing green or amber
on the Network LED.
5. Reinstall the camera, referring to the installation guide.
If the emergency recovery procedure does not get the camera up and running again, please
contact Axis support at www.axis.com/techsup/
Axis Support
If you contact Axis support, please help us
to help you solve your problems by providing
the server report, the log file and a detailed description of the problem.
Server Report - go
to Setup > System Options > Support Overview. The server report
contains important information about the server and its software, as well as a list of the
current parameters.
The Log
file is available from Setup > System Options > Logs & Reports. The Log file
records events in the unit since the last system restart and can be a useful diagnostic tool
when troubleshooting.
