Rev1.7

1.3.6.1.4.1.2699.1.4.1.11.1.1.3 pdmTempSwitchStatus INTEGER 4 byte R Unsupported.

1.3.6.1.4.1.2699.1.4.1.11.1.1.4 pdmTempSwitchErrorCounter Counter32 4 byte R Unsupported.

1.3.6.1.4.1.2699.1.4.1.11.1.1.5 pdmTempSwitchReset INTEGER 4 byte R/W Unsupported.

1.3.6.1.4.1.2699.1.4.1.11.1.1.6 pdmTempSwitchReplaceCount Counter32 4 byte R Unsupported.

1.3.6.1.4.1.2699.1.4.1.11.1.1.7 pdmTempSwitchReplaceTime OCTET STRING 19〜25 byte R Unsupported.

1.3.6.1.4.1.2699.1.4.1.11.1.1.8 pdmTempSwitchReplacePN OCTET STRING 255 byte R/W Unsupported.

1.3.6.1.4.1.2699.1.4.1.12.1.1.2 pdmConnectorDescription OCTET STRING 255 byte R GET: Get SPACE always.

1.3.6.1.4.1.2699.1.4.1.12.1.1.3 pdmConnectorType INTEGER 4 byte R

GET: Get current input as;

VGA: vga(3),

RGB/HV: other(1),

DVI: dviD(4),

HDMI: hdmi(6),

VIDEO1: rcaPlugVideo3(13),

S-VIDEO: sVideo(10),

DisplayPort: displayPort(9),

Others: unknown(2).

1.3.6.1.4.1.2699.1.4.1.12.1.1.4 pdmConnectorEnabled INTEGER 4 byte R/W

GET: Get "TRUE(1)" always.

SET: Unsupported.

1.3.6.1.4.1.2699.1.4.1.12.1.1.5 pdmConnectorAudioAdjust Integer32 4 byte R/W

GET: Get "0 (zero)" always.

SET: Unsupported.

1.3.6.1.4.1.2699.1.4.1.12.1.1.6 pdmConnectorVideoAdjust Integer32 4 byte R/W

GET: Get "0 (zero)" always.

SET: Unsupported.

1.3.6.1.4.1.2699.1.4.1.12.2 pdmConnectorVideoCurrInput Integer32 4 byte R/W

GET: Get "0 (zero)" always.

SET: Unsupported.

1.3.6.1.4.1.2699.1.4.1.12.3 pdmConnectorAudioCurrInput Integer32 4 byte R/W

GET: Get "0 (zero)" always.

SET: Unsupported.

1.3.6.1.4.1.2699.1.4.1.13.1.1.2 pdmInterlockDescription OCTET STRING 255 byte R Unsupported.

1.3.6.1.4.1.2699.1.4.1.13.1.1.3 pdmInterlockStatus INTEGER 4 byte R Unsupported.

1.3.6.1.4.1.2699.1.4.1.14.1.1.2 pdmLocaleCharsetEnum Integer32 4 byte R GET: Get "0 (zero)" always.

1.3.6.1.4.1.2699.1.4.1.14.2 pdmLocaleCharsetEnumEWS Integer32 4 byte R/W

GET: Get "0 (zero)" always.

SET: Unsupported.

1.3.6.1.4.1.2699.1.4.1.15.1.1.2 pdmLocaleLanguageTag OCTET STRING 63 byte R GET: Get SPACE always.

1.3.6.1.4.1.2699.1.4.1.15.2 pdmLocaleLanguageTagEWS OCTET STRING 63 byte R/W

GET: Get "en-US" always.

SET: Unsupported.

1.3.6.1.4.1.2699.1.4.1.15.3 pdmLocaleLanguageTagOSD OCTET STRING 63 byte R/W

GET: Get SPACE always.

SET: Unsupported.

1.3.6.1.4.1.2699.1.4.1.15.4 pdmLocaleLanguageTagWSM OCTET STRING 63 byte R/W

GET: Get SPACE always.

SET: Unsupported.

1.3.6.1.4.1.2699.1.4.1.16.1 pdmAudioDescription OCTET STRING 255 byte R GET: Get SPACE always.

1.3.6.1.4.1.2699.1.4.1.16.2 pdmAudioVolume INTEGER 4 byte R/W

GET: Get current Audio Volume value (0 - 100).

SET: Set to change the Audio Volume value (0 - 100).

1.3.6.1.4.1.2699.1.4.1.16.3 pdmAudioMute INTEGER 4 byte R/W

GET: Get current Audio Mute condition as;

MUTE: 1.

MUTE CANCEL: 0.

SET: Set to change Audio Mute condition as;

1: MUTE

0: MUTE CANCEL.

*If it is "OPTION POWER =ON", This function can be set up also in

the "Standby mode".

1.3.6.1.4.1.2699.1.4.1.16.4 pdmAudioTreble Integer32 4 byte R/W

GET: Get current Audio Treble value (0 - 100).

SET: Set to change the Audio Treble value (0 - 100).

1.3.6.1.4.1.2699.1.4.1.16.5 pdmAudioBass Integer32 4 byte R/W

GET: Get current Audio Bass value (0 - 100).

SET: Set to change the Audio Bass value (0 - 100).

1.3.6.1.4.1.2699.1.4.1.16.6 pdmAudioBalance Integer32 4 byte R/W

GET: Get current Audio Balance value (0 - 100).

SET: Set to change the Audio Balance value (0 - 100).

1.3.6.1.4.1.2699.1.4.1.17.1.1.2 pdmButtonDescription OCTET STRING 255 byte R GET: Get ”Key/IR Lock”

1.3.6.1.4.1.2699.1.4.1.17.1.1.3 pdmButtonEnabled INTEGER 4 byte R/W

GET: Get the Control Panel Key Lock and IR Control status as;

UNLOCK: true(1),

LOCK: false(2).

SET: Set to change the Control Panel Key Lock and IR Control

status as;

true(1): UNLOCK,

false(2): LOCK.

GET: Get the error status when it has one error, as;

Power supply is abnormal: "7X POWER",

FAN is abnormal: "8X FAN",

Inverter is abnornmal: "9X INVERTER"

Temperature is abnormal: "AX TEMPARATURE"

Signal changed: "BX SIGNAL" Unsupport Support

Option is abnormal: "CX OPTION". Unsupport Support

If it has two or more errors, get "General".

GET: Get the error status as;

Standby-power +3.3V abnormality: "Power_0",

Standby-power +5V abnormality: "Power_1",

Panel-power +12V abnormality: "Power_2",

Main-power +2.5V abnormality: "Power_3", Support Unsupport

Main-power +1.8V abnormality: "Power_4", Support Unsupport

Main-power +5V abnormality: "Power_5",

Sub-power +3.3V abnormality: "Power_6",

Main-power +3.3V abnormality: "Power_7",

Inverter/Option-power +24V abnormality: "Power_8", Unsupport Support

Cooling fan-1 abnormality: "Fan_0",

Cooling fan-2 abnormality: "Fan_1",

Cooling fan-3 abnormality: "Fan_2", Support Unsupport

Inverter abnormality: "Inverter_0", Support Unsupport

LED backlight abnormality: "Backlight_1" Unsupport Support

Tenperature abnormality – shutdown: "Temperature_0",

Tenperature abnormality – half brightness: "Temperature_1".

Sensor reached the user setting temperature: "Temperature_2" Unsupport Support

No Signal: "Signal_0" Unsupport Support

Option board abnormality: Option_0" Unsupport Support

Support

OCTET STRINGpdmAlertGroupType1.3.6.1.4.1.2699.1.4.1.18.1.1.2

R255 byteOCTET STRINGpdmAlertGroupId1.3.6.1.4.1.2699.1.4.1.18.1.1.3

R255 byte

Unsupport

Support

Unsupport

Support
