3. Connect your appliance to gas cock from the shortest way and in

a manner to prevent any leakage. For safety, the hose used should be

maximum 125 cm and minimum 40 cm.

4. While making gas leakage control; never use lighter, match, glowing

cigarette or similar inammable matter.

5. Apply soap bubble on connection point. If any leak/leakage exists,

foaming will occur on soaped region.

6. If the cooktop is to be mounted on a cabinet or openable drawer,

a heat protection panel having 15 mm minimum opening should be

mounted under the cooktop.

IF BUILT-IN OVEN IS PLACED UNDER COOKTOP;

Gas pipe should be afxed in a way not to touch the oven below, sharp

edges and corners, not to be pulled in a manner to be twisted and

strained. Make gas connection from right part of the cooktop, fasten

the hose by use of clamp.

INSTALLATION OF COOKSTOP

1. Detach the burners, burner hoods and grills from the product.

2. Turn the cooktop down and place on smooth ground.

3. In order to prevent entrance of foreign substances and liquids

between cooktop and counter, apply the paste given in package to the

sides of lower guard of counter. For corners, curl paste and increase

curls till lling corner gaps.

4. Turn cooktop again and align with and place on counter.

5. Fasten up your cooktop on counter by using the clamp and screws

supplied.

On the assembly chart given in next page, it is shown how to assemble

your cooktop.

Cooktop

Hose

Oven

Figure 1
