12 ENGLISH
2 Technical Data
HD 11/90
HD 13/100
HD 17/190
HD 19/180B
Flow rate (l/min) .......................
11 ...................
13 .................
17 .......................
19
Max. working length (m) ...........
10 ...................
20 .................
40 .......................
40
Max. operating pressure ..........
90 bar .............
100 bar .........
190 bar ...............
180 bar
Motor .......................................
230V / 50Hz ....
230V / 50Hz ..
230V / 50Hz ........
petrol
Speed (1/min) ..........................
1400 ................
1400 .............
2800 ...................
1800
Motor capacity (kW) .................
1,5 ..................
2,3 ................
5,0 ......................
8,1
Current consumption ................
9,5 A ...............
13 A ..............
400V-10,9A .........
3x230V-18,8A
---
Consumption/Tank contents ....
--- ....................
--- ..................
--- ........................
3,2l/h / 6,5l
Dimensions (cm) ......................
48 x 24 x 35 ....
65 x 50 x 70 ..
65 x 50 x 70 ........
65 x 50 x70
Weight (kg) ..............................
29,5 .................
45 .................
50 .......................
78,5
High-pressure hose .................
NW6 x 10m .....
NW6 x 20m ...
NW8 x 40m .........
NW8 x 40m
Typical A-rated sound level:
Noise pressure level dB (A)
L
pA
¦ K
pA
....................................
68 ¦ 3 ...............
76 ¦ 3 .............
79 ¦ 3 ..................
81 ¦ 3
Sound power level dB (A)
L
WA
¦ K
WA
..................................
79 ¦ 3 ...............
87 ¦ 3 .............
90 ¦ 3 ..................
92 ¦ 3
The noise level during operation can exceed 85 dB (A). Wear hearing protection!
Measured values determined in accordance with EN 60745-1:2010.
3 Function of the Unit
3.1 Overview (A)
1
Adaptor for high-pressure hose
Valves
2
Water inflow
Connecting hose pump - reel
3
Injector adaptor
Mounting for washing lance
4
Pressure control valve
Petrol motor (HD19/180B)
5
Pressure gauge
3.2 Functional description
The high-pressure pipe cleaning devices are self-priming compact devices for cleaning pipes,
drains, downpipes, house service connections, rain downpipes and for cleaning work in ducts of
the following diameters:
HD 11/90 and HD 13/100 dia. 40 – 150 mm up to a maximum length of 30 m
HD 17/190 and HD 19/180B dia. 40 – 200 mm up to a maximum length of 40 m
All types are equipped with:
• Continuously variable pressure regulation
• A pump with 3 ceramic plungers running in an oil bath, run-dry safe, stainless steel valves,
brass pump housing, leak refeed, pressure gauge with bar/psi scale, self-priming up to 2 m
• Integrated suction injector, solvent feed outside of the pump, thus no damage to the high-
pressure seal.
When using a washing lance (accessory item no.: 76088 / 76073) the high-pressure cleaners al-
so serve to clean the surfaces of motor vehicles, buildings, machines, etc.
