COMPATIBILITY

The contact sensor works with the Z1 ZigBee Bridge and the ICS-2000.

1. (RE)PLACE THE BATTERY

Remove the backplate from the contact sensor.

Open de battery cover using a ﬂat screwdriver.

Place the included CR2032 battery in the contact sensor. Note the positive

and negative polarity in the compartment. Close the battery cover.

2. INDICATORS

The contact sensor contains a LED indicator (This is not a button) to show the

status of the contact sensor. Please see below the meaning of the dierent

LED indications.

LED FUNCTION TABLE

Connection mode LED will ﬂash once per second

for approximately 1 min.

Connected successfully LED will stop ﬂashing

Sensor reset LED will ﬂash fast

Sensor triggered (When the sensor is

opened for more then 10 mm)

LED will ﬂash once
