English 26
Legend:
E - Electronic model
M - Electro-mechanical model
Unit does not respond
properly to remote
control command.
Operating indicator
blinks.
Filter indicator lights
up.
Noise from the outdoor
unit.
IR signal does not reach unit.
Distance between remote
control and unit is too great
or remote control unit is
aimed at improper angle.
IR receiver on unit is exposed
to strong light source.
Compressor operates at high
pressure.
Air filter is contaminated.
The outdoor condensate
pump is operating without
water.
Check for obstruction
between unit and remote
control; clear if needed.
Get closer to unit.
Dim lights, especially
fluorescent.
Normal operation of the air
conditioner.
Open a door or a window.
Clean filter, reinstall it and
reset indicator.
Regular operation of the air
conditioner.
PROBLEM
CAUSE SOLUTION
EM
x
x
x
xx
