138

4. The R&D department and marketing department can not communicate with each other.

¾ Network Diagram

¾ Configuration Procedure

Step Operation Description

1 Configure

Time-range

On ACL→Time-Range page, create a time-range named work_time.

Select Week mode and configure the week time from Monday to Friday.

Add a time-slice 08:00~18:00.

2 Configure for

requirement 1

On ACL→ACL Config→ACL Create page, create ACL 11.

On ACL→ACL Config→MAC ACL page, select ACL 11, create Rule 1,

configure the operation as Permit, configure the S-MAC as

00-45-A5-5D-12-C3 and mask as FF-FF-FF-FF-FF-FF, and configure

the time-range as No Limit.

On ACL→Policy Config→Policy Create page, create a policy named

manager.

On ACL→Policy Config→Action Create page, add ACL 11 to Policy

manager.

On ACL→Policy Binding→Port Binding page, select Policy manager

to bind to port 3.
