English | 17
Bosch Power Tools 2 609 932 747 | (13.8.10)
The severed plug must be disposed of to avoid a
possible shock hazard and should never be in-
serted into a mains socket elsewhere.
Products sold in AUS and NZ only: Use a resid-
ual current device (RCD) with a rated residual
current of 30 mA or less.
Functional Description
Read all safety warnings and all in-
structions. Failure to follow the
warnings and instructions may re-
sult in electric shock, fire and/or se-
rious injury.
While reading the operating instructions, unfold
the graphics page for the machine and leave it
open.
Intended Use
The machine is intended for impact drilling in
brick, concrete and stone, dry drilling (not suit-
able for wet drilling) with diamond-tipped core
bits in bricks and lime-sand brick, as well as for
drilling in wood, metal ceramics and plastic. Ma-
chines with electronic control and right/left ro-
tation are also suitable for screwdriving and
thread-cutting.
Product Features
The numbering of the product features refers to
the illustration of the machine on the graphics
page.
1 Key-type drill chuck with automatic locking
feature
2 “Drilling/Impact Drilling” selector switch
3 Rotational direction switch
4 Lock-on button for On/Off switch
5 On/Off switch
6 Thumbwheel for speed preselection
7 Depth stop
8 Gear selector
9 Wing bolt for depth stop adjustment
10 Auxiliary handle (insulated gripping surface)
11 Handle (insulated gripping surface)
12 Chuck key
13 Screwdriver bit*
14 Universal bit holder*
15 Chuck key for key-type drill chuck
(manual locking) *
16 Key-type drill chuck (manual locking) *
17 Open-end spanner**
*Accessories shown or described are not part of the
standard delivery scope of the product. A complete
overview of accessories can be found in our acces-
sories program.
**Commercially available (not included in the deliv-
ery scope)
Technical Data
Impact Drill GSB 162-2 RE
Professional
Article number
3 601 A8B 0..
Rated power input
W 1500
Output power
W 840
No-load speed
– 1st gear
– 2nd gear
min
-1
min
-1
0 – 750
0 – 2550
Rated speed
– 1st gear
– 2nd gear
min
-1
min
-1
555
1890
Impact frequency at
no-load
– 1st gear
– 2nd gear
min
-1
min
-1
12750
43350
Rated torque
(1st/2nd gear)
Nm 16.4/4.8
Spindle collar dia.
mm 53
Maximum drilling diam-
eter (1st/2nd gear)
–Concrete
– Brickwork
– Steel
–Wood
mm
mm
mm
mm
82/68
162/68
20/14
50/30
Chuck clamping range
mm 3 – 16
Weight according
to EPTA-Procedure
01/2003
kg 4.8
Protection class
/II
The values given are valid for a nominal voltage [U] of
230 V. For different voltages and models for specific
countries, these values can vary.
Please observe the article number on the type plate of
your machine. The trade names of the individual ma-
chines may vary.
OBJ_BUCH-1294-001.book Page 17 Friday, August 13, 2010 11:41 AM
