TL-PA211

AV200 Mini Powerline Adapter

To upgrade the device's firmware, follow these instructions:

1. Download PIB file and firmware upgrade file from the TP-LINK website (www.tp-link.com).

2. Enter the path name or click Browse… to select the downloaded files on the computer into the

corresponding blanks.

3. Click the OK button.



Note:

Do not turn off the device while the firmware is being upgraded. The device will reboot after the

Upgrading has been finished.

 “x” Powerline Devices detected: This display all the Mini Powerline Adapter found on the current

logical network. “x” shows the number of remote Mini Powerline Adapter discovered by this

Management Utility.

 Network Type: Displayed the type of logical network: “Public” or “Private”.

 Autoscan: Shows the scanning status (Default is “ON”).

 Device Name: Shows the default device name. One may redefine or change the name by

clicking on the name and editing in place or by clicking the “Rename” button.

 Password: Shows the current password of the Mini Powerline Adapter.

 Quality: Shows the quality of the Mini Powerline Adapter connection.

 Rate (Mbps): Shows the current transmission rate of the selected Mini Powerline Adapter.

 MAC Address: Shows the Mini Powerline Adapter‟s MAC address.

 Rename: Click to change the name of the selected Mini Powerline Adapter.

 Enter Password: Shows the supplied Mini Powerline Adapter‟s password (Initially left blank). To set

the Mini Powerline Adapter password (Which is required when creating a private network), click and

select the device shown in the lower panel and click on the “Enter Password” button. Follow the

pop-up dialog box to complete your password setting.

 Add: Click this button to add a remote Mini Powerline Adapter to your network that is not on the

lower panel displayed list. You will advice to locate the passwords for all Mini Powerline Adapter you

wish to manage and add them to the local logical network by clicking the “Add” button. Follow the

pop-up dialog box to complete your setting.

 Scan: Click the “Scan” button to perform an immediate search of the Mini Powerline Adapter

connected to the computer. The Management Utility will automatically perform the scanning process

and update the display every few seconds by default.

4.1.1 Rename

This Management Utility allows you to change the name of the listed Mini Powerline Adapter. Click and

select the Mini Powerline Adapter you wish to change from the list, then click on the “Rename” tab and

editing-in-place to change the name.
