GA-MA770T-US3 (rev.1.4)
Инструкция по эксплуатации Страница: 2

Gigabyte GA-MA770T-US3 (rev.1.4) Инструкция по эксплуатации онлайн [2/100] 41749

Motherboard

GA-MA770T-UD3/

GA-MA770T-US3

Jul. 2, 2010

Motherboard

GA-MA770T-UD3/GA-MA770T-US3

Содержание

Ga ma770t ud3 ga ma770t us3 1
User s manual 1
Copyright 3
Disclaimer 3
Documentation classifications 3
Identifying your motherboard revision 3
Box contents 6 optional items 6 ga ma770t ud3 us3 motherboard layout 7 block diagram 8 4
Chapter 1 hardware installation 9 4
Chapter 2 bios setup 33 4
Table of contents 4
Chapter 3 drivers installation 57 5
Chapter 4 unique features 61 5
Chapter 5 appendix 73 5
Box contents 6
Optional items 6
Ga ma770t ud3 us3 7
Ga ma770t ud3 us3 motherboard layout 7
The ga ma770t ud3 adopts all solid capacitor design 7
Block diagram 8
1 installation precautions 9
Chapter 1 hardware installation 9
2 product specifications 10
3 1 installing the cpu 13
3 installing the cpu and cpu cooler 13
3 2 installing the cpu cooler 15
4 1 dual channel memory configuration 16
4 installing the memory 16
4 2 installing a memory 17
5 installing an expansion card 18
6 back panel connectors 19
Coaxial s pdif out connector 19
Ieee 1394a port 19
Optical s pdif out connector 19
Ps 2 keyboard and ps 2 mouse port 19
Rj 45 lan port 19
Usb port 19
Center subwoofer speaker out jack orange 20
Line in jack blue 20
Line out jack green 20
Mic in jack pink 20
Rear speaker out jack black 20
Side speaker out jack gray 20
7 internal connectors 21
2 atx_12v_2x4 atx 2x4 12v power connector and 2x12 main power connector 22
Ga ma770t ud3 us3 motherboard 22 22
To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 22
With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 22
4 5 cpu_fan sys_fan1 sys_fan2 pwr_fan fan headers 23
Be sure to connect fan cables to the fan headers to prevent your cpu and system from overheating overheating may result in damage to the cpu or the system may hang these fan headers are not configuration jumper blocks do not place a jumper cap on the headers 23
Fdd floppy disk drive connector 23
Hardware installation 23 23
The motherboard has a 4 pin cpu fan header cpu_fan a 3 pin sys_fan2 and a 4 pin sys_fan1 system fan headers and a 3 pin power fan header pwr_fan most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the motherboard supports cpu fan speed control which requires the use of a cpu fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis 23
This connector is used to connect a floppy disk drive the types of floppy disk drives supported are 360 kb 720 kb 1 mb 1 4 mb and 2 8 mb before connecting a floppy disk drive be sure to locate pin 1 of the connector and the floppy disk drive cable the pin 1 of the cable is typically designated by a stripe of different color 23
A raid 0 or raid 1 configuration requires at least two hard drives if more than two hard drives are to be used the total number of hard drives must be an even number a raid 10 configuration requires at least four hard drives and the total number of hard drives must be an even number 24
Ga ma770t ud3 us3 motherboard 24 24
Ide ide connector 24
Pin no definition 24
Please connect the l shaped end of the sata cable to your sata hard drive 24
Sata2_0 1 2 3 4 5 sata 3gb s connectors 24
The ide connector supports up to two ide devices such as hard drives and optical drives before attaching the ide cable locate the foolproof groove on the connector if you wish to connect two ide devices remember to set the jumpers and the cabling according to the role of the ide devices for example master or slave for information about configuring master slave settings for the ide devices read the instructions from the device manufacturers 24
The sata connectors conform to sata 3gb s standard and are compatible with sata 1 gb s standard each sata connector supports a single sata device the amd sb710 controller supports raid 0 raid 1 raid 10 and jbod refer to chapter 5 configuring sata hard drive s for instructions on configuring a raid array 24
Always turn off your computer and unplug the power cord before replacing the battery replace the battery with an equivalent one danger of explosion if the battery is replaced with an incorrect model contact the place of purchase or local dealer if you are not able to replace the battery by yourself or uncertain about the battery model when installing the battery note the orientation of the positive side and the negative side of the battery the positive side should face up used batteries must be handled in accordance with local environmental regulations 25
Bat battery 25
Hardware installation 25 25
Pwr_led system power led header 25
The battery provides power to keep the values such as bios configurations date and time information in the cmos when the computer is turned off replace the battery when the battery voltage drops to a low level or the cmos values may not be accurate or may be lost 25
This header can be used to connect a system power led on the chassis to indicate system power status the led is on when the system is operating the led keeps blinking when the system is in s1 sleep state the led is off when the system is in s3 s4 sleep state or powered off s5 25
F_panel front panel header 26
Cd_in cd in connector 27
F_audio front panel audio header 27
Hardware installation 27 27
The front panel audio header supports hd audio by default if your chassis provides an ac 97 front panel audio module refer to the instructions on how to activate ac 97 functionality via the audio software in chapter 5 configuring 2 4 5 7 channel audio audio signals will be present on both of the front and back panel audio connections simultaneously if you want to mute the back panel audio only supported when using an hd front panel audio module refer to chapter 5 configuring 2 4 5 7 channel audio some chassis provide a front panel audio module that has separated connectors on each wire instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 27
The front panel audio header supports intel high definition audio hd and ac 97 audio you may connect your chassis front panel audio module to this header make sure the wire assignments of the module connector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 27
You may connect the audio cable that came with your optical drive to the header 27
Ga ma770t ud3 us3 motherboard 28 28
Spdif_in s pdif in header 28
Spdif_out s pdif out header 28
This header supports digital s pdif in and can connect to an audio device that supports digital audio out via an optional s pdif in cable for purchasing the optional s pdif in cable please contact the local dealer 28
This header supports digital s pdif out and connects a s pdif digital audio cable provided by expansion cards for digital audio output from your motherboard to certain expansion cards like graphics cards and sound cards for example some graphics cards may require you to use a s pdif digital audio cable for digital audio output from your motherboard to your graphics card if you wish to connect an hdmi display to the graphics card and have digital audio output from the hdmi display at the same time for information about connecting the s pdif digital audio cable carefully read the manual for your expansion card 28
Do not plug the ieee 1394 bracket 2x5 pin cable into the usb header prior to installing the usb bracket be sure to turn off your computer and unplug the power cord from the power outlet to prevent damage to the usb bracket 29
Do not plug the usb bracket cable into the ieee 1394a header prior to installing the ieee 1394a bracket be sure to turn off your computer and unplug the power cord from the power outlet to prevent damage to the ieee 1394a bracket to connect an ieee 1394a device attach one end of the device cable to your computer and then attach the other end of the cable to the ieee 1394a device ensure that the cable is securely connected 29
F_1394 ieee 1394a header 29
F_usb1 f_usb2 usb headers 29
Hardware installation 29 29
The header conforms to ieee 1394a specification the ieee 1394a header can provide one ieee 1394a port via an optional ieee 1394a bracket for purchasing the optional ieee 1394a bracket please contact the local dealer 29
The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 29
Coma serial port header 30
Ga ma770t ud3 us3 motherboard 30 30
Lpt parallel port header 30
The com header can provide one serial port via an optional com port cable for purchasing the optional com port cable please contact the local dealer 30
The lpt header can provide one parallel port via an optional lpt port cable for purchasing the optional lpt port cable please contact the local dealer 30
Ci chassis intrusion header 31
Clr_cmos clearing cmos jumper 31
Chapter 2 bios setup 33
1 startup screen 34
A the logo screen default 34
B the post screen 34
2 the main menu 35
Bios setup program function keys 35
Sample bios version ga ma770t ud3 e1 35
Advanced bios features 36
Exit without saving 36
Integrated peripherals 36
Keys for the main menu only 36
Load fail safe defaults 36
Load optimized defaults 36
Mb intelligent tweaker m i t 36
Pc health status 36
Power management setup 36
Save exit setup 36
Set supervisor password 36
Set user password 36
Standard cmos features 36
3 mb intelligent tweaker m i t 37
37 bios setup 37
Advanced clock calibratioin 37
Whether the system will work stably with the overclock overvoltage settings you made is dependent on your overall system configurations incorrectly doing overclock overvoltage may result in damage to cpu chipset or memory and reduce the useful life of these components this page is for advanced users only and we recommend you not to alter the default settings to prevent system instability or other unexpected results inadequately alter ing the settings may result in system s failure to boot if this occurs clear the cmos values and reset the board to default values when the system voltage optimized item blinks in red it is recommended that you set the system voltage control item to auto to optimize the system voltage settings 37
Advanced clock calibration 38
Cpu clock ratio 38
Cpu frequency mhz 38
Cpu host clock control 38
Cpu northbridge freq 38
Ht link frequency 38
Memory clock 38
Pcie clock mhz 38
Set memory clock 38
Value all cores 38
Value core 0 value core 1 value core 2 value core 3 38
39 bios setup 39
Allows you to set memory control mode 39
Cpu host clock control cpu frequency mhz set memory clock memory clock 39
Dcts mode 39
Ddr3 timing items 39
Dram configuration 39
Ganged sets memory control mode to single dual channel 39
Manual allows all ddr3 timing items below to be configurable options are auto default manual 39
The settings under the four items above are synchronous to those under the same items in the mb intelligent tweaker m i t 39
Unganged sets memory control mode to two single channel default 39
Cas latency 40
Cpu nb vid control 40
Minimum ras active time 40
Precharge time 40
Ras to cas r w delay 40
Ras to ras delay 40
Row cycle time 40
Row precharge time 40
System voltage control 40
T 2t command timing 40
Trfc0 for dimm1 40
Trfc1 for dimm3 40
Trfc2 for dimm2 40
Trfc3 for dimm4 40
Twtr command delay 40
Write recovery time 40
Cpu voltage control 41
Ddr vtt voltage control 41
Dram voltage control 41
Nb pcie voltage control 41
Nb voltage control 41
Normal cpu vcore 41
Sb ht voltage control 41
4 standard cmos features 42
Access mode sets the hard drive access mode options are auto default chs lba large 42
Access mode sets the hard drive access mode options are auto default large 42
Extended ide drive configure your ide sata devices by using one of the two methods below auto lets bios automatically detect ide sata devices during the post default none if no ide sata devices are used set this item to none so the system will skip the detection of the device during the post for faster system startup 42
Ga ma770t ud3 us3 motherboard 42 42
Ide channel 0 1 master slave 42
Ide channel 0 1 master slave configure your ide sata devices by using one of the two methods below auto lets bios automatically detect ide sata devices during the post default none if no ide sata devices are used set this item to none so the system will skip the detection of the device during the post for faster system startup 42
Ide channel 2 3 master slave 42
Sets the system date the date format is week read only month date and year select the desired field and use the up arrow or down arrow key to set the date 42
Sets the system time for example 1 p m is 13 0 0 select the desired field and use the up arrow or down arrow key to set the time 42
To autodetect the parameters of the ide sata device on this channel 42
Drive a 43
Floppy 3 mode support 43
Halt on 43
Memory 43
5 advanced bios features 44
Amd k8 cool quiet control 44
Auto lets the amd cool n quiet driver dynamically adjust the cpu clock and via to reduce heat output from your computer and its power consumption default 44
Disabled disables this function 44
First second third boot device 44
Ga ma770t ud3 us3 motherboard 44 44
Hard disk boot priority 44
Password check 44
Setup a password is only required for entering the bios setup program default 44
Specifies whether a password is required every time the system boots or only when you enter bios setup after configuring this item set the password s under the set supervisor user password item in the bios main menu 44
System a password is required for booting the system and for entering the bios setup program 44
To accept options are floppy ls120 hard disk cdrom zip usb fdd usb zip usb cdrom usb hdd legacy lan disabled 44
To exit this menu when finished 44
Virtualization 44
Virtualization allows a platform to run multiple operating systems and applications in independent partitions with virtualization one computer system can function as multiple virtual systems default disabled 44
Away mode 45
Backup bios image to hdd 45
Full screen logo show 45
Hdd s m a r t capability 45
Init display first 45
6 integrated peripherals 46
Allows you to decide whether to activate the boot rom integrated with the onboard lan chip default disabled 46
Enables or disables the integrated ide controller default enabled 46
Enables or disables the onboard ieee 1394 function default enabled 46
Enables or disables the onboard lan function default enabled if you wish to install a 3rd party add in network card instead of using the onboard lan set this item to disabled 46
Ga ma770t ud3 us3 motherboard 46 46
Onboard 1394 function 46
Onboard lan boot rom 46
Onboard lan function 46
Onchip ide channel 46
Smart lan lan cable diagnostic function 47
Legacy usb storage detect 48
Onboard audio function 48
Onboard parallel port 48
Onboard serial port 1 48
Onchip sata controller 48
Onchip sata port4 5 mode sata2_4 sata2_5 connectors 48
Onchip sata type sata2_0 sata2_3 connectors 48
Onchip usb controller 48
Usb ehci controller 48
Usb keyboard support 48
Usb mouse support 48
Ecp mode use dma 49
Parallel port mode 49
7 power management setup 50
Acpi suspend type 50
Allows the system to be awakened from acpi s3 sleep state by a wake up signal from the installed usb device default enabled 50
Allows the system to be awakened from an acpi sleep state by a wake up signal from a modem that supports wake up function default disabled 50
Configures the way to turn off the computer in ms dos mode using the power button 50
Delay 4 sec press and hold the power button for 4 seconds to turn off the system if the power button is pressed for less than 4 seconds the system will enter suspend mode 50
Ga ma770t ud3 us3 motherboard 50 50
Instant off press the power button and then the system will be turned off instantly default 50
Modem ring resume 50
Note supported on window 50
Operating system only 50
S1 pos enables the system to enter the acpi s1 power on suspend sleep state in s1 sleep state the system appears suspended and stays in a low power mode the system can be resumed at any time 50
S3 str enables the system to enter the acpi s3 suspend to ram sleep state default in s3 sleep state the system appears to be off and consumes less power than in the s1 state when signaled by a wake up device or event the system resumes to its working state exactly where it was left off 50
Soft off by power button 50
Specifies the acpi sleep state when the system enters suspend 50
Usb wake up from s3 50
Ac back function 51
Erp support 51
Hpet support 51
Kb power on password 51
Pme event wake up 51
Power on by alarm 51
Power on by keyboard 51
Power on by mouse 51
8 pc health status 52
Case opened 52
Displays the detection status of the chassis intrusion detection device attached to the motherboard ci header if the system chassis cover is removed this field will show yes otherwise it will show no to clear the chassis intrusion status record set reset case open status to enabled save the settings to cmos and then restart your system 52
Ga ma770t ud3 us3 motherboard 52 52
Keeps or clears the record of previous chassis intrusion status enabled clears the record of previous chassis intrusion status and the case opened field will show no at next boot default disabled 52
Reset case open status 52
Cpu smart fan control 53
Cpu smart fan mode 53
Cpu system power fan fail warning 53
Cpu warning temperature 53
Current cpu system power fan speed rpm 53
Current system cpu temperature 53
Current voltage v vcore ddr3 1 v 3 v 12v 53
System smart fan control 53
10 load optimized defaults 54
9 load fail safe defaults 54
Ga ma770t ud3 us3 motherboard 54 54
Key to load the optimal bios default settings the bios defaults settings helps the system to operate in optimum state always load the optimized defaults after updating the bios or after clearing the cmos values 54
Key to load the safest bios default settings in case system instability occurs you may try to load fail safe defaults which are the safest and most stable bios settings for the motherboard 54
11 set supervisor user password 55
12 save exit setup 56
13 exit without saving 56
Ga ma770t ud3 us3 motherboard 56 56
To return to the bios setup main menu 56
1 installing chipset drivers 57
Chapter 3 drivers installation 57
2 application software 58
3 technical manuals 58
4 contact 59
5 system 59
6 download center 60
1 xpress recovery2 61
A installing windows vista and partitioning the hard drive 61
Before you begin 61
Chapter 4 unique features 61
Installation and configuration 61
System requirements 61
B accessing xpress recovery2 62
C using the backup function in xpress recovery2 62
D using the restore function in xpress recovery2 63
E removing the backup 63
F exiting xpress recovery2 63
2 1 updating the bios with the q flash utility 64
2 bios update utilities 64
A before you begin 64
B updating the bios 65
Ga ma770t ud3 us3 motherboard 66 66
To exit q flash and reboot the system as the system boots you should see the new bios version is present on the post screen 66
To load bios defaults 66
To load bios defaults system will re detect all peripherals devices after a bios update so we recommend that you reload bios defaults 66
To save settings to cmos and exit bios setup the procedure is complete after the system restarts 66
2 2 updating the bios with the bios utility 67
A before you begin 67
B using bios 67
C after updating the bios 67
3 easytune 6 68
Ga ma770t ud3 us3 motherboard 68 68
Gigabyte s easytune 6 is a simple and easy to use interface that allows users to fine tune their system settings or do overclock overvoltage in windows environment the user friendly easytune 6 interface also includes tabbed pages for cpu and memory information letting users read their system related information without the need to install additional software 68
Tab function 68
Tabs information 68
The easytune 6 interface 68
4 easy energy saver 69
Meter mode button information table 69
The easy energy saver interface a meter mode 69
B total mode 70
C stealth mode 70
Total mode button information table 70
5 q share 71
Directions for using q share 71
Options descriptions 71
6 time repair 72
Preference screen 72
System restore 72
1 1 configuring the onboard sata controller 73
1 configuring sata hard drive s 73
A installing sata hard drive s in your computer 73
Before you begin 73
Chapter 5 appendix 73
To configure sata hard drive s follow the steps below 73
B configuring sata controller mode in bios setup 74
Figure 1 74
Ga ma770t ud3 us3 motherboard 74 74
Make sure to configure the sata controller mode correctly in system bios setup 74
Step 2 save changes and exit bios setup 74
The bios setup menus described in this section may differ from the exact settings for your motherboard the actual bios setup menu options you will see shall depend on the motherboard you have and the bios version 74
To enter bios setup during the post power on self test ensure onchip sata controller is enabled under integrated peripherals to enable raid for the sata2_0 1 2 3 connectors set onchip sata type to raid to enable raid for the sata2_4 sata2_5 connectors set onchip sata type to raid and set onchip sata port4 5 type to as sata type figure 1 74
C configuring raid set in raid bios 75
Figure 4 76
Figure 5 76
Ga ma770t ud3 us3 motherboard 76 76
To enter the define ld window figure 4 the define ld selection from the main menu allows users to begin the process of manually defining the drive elements and raid levels for one or multiple disk arrays attached to the amd sb710 controller 76
To enter the raid configuration menu figure 5 76
Delete an array the delete array menu option allows for deletion of disk array assignments 78
Deleting an existing disk array could result in loss of data record all array information including the array type the disk members and stripe block size in case you wish to undo a deletion 78
Figure 9 78
Ga ma770t ud3 us3 motherboard 78 78
To return to main menu 78
1 2 making a sata raid ahci driver diskette for windows xp 79
Required for ahci and raid mode 79
1 3 installing the sata raid ahci driver and operating system 80
A installing windows xp 80
B installing windows vista 81
2 1 configuring 2 4 5 7 channel audio 84
2 configuring audio input and output 84
A configuring speakers 84
B configuring sound effect 85
C activating an ac 97 front panel audio module 85
D muting the back panel audio for hd audio only 85
2 2 configuring s pdif in out 86
A s pdif in 86
B s pdif out 87
2 3 configuring microphone recording 88
Enabling stereo mix 89
2 4 using the sound recorder 90
A recording sound 90
B playing the recorded sound 90
3 1 frequently asked questions 91
3 troubleshooting 91
Appendix 91 91
To read more faqs for your motherboard please go to the support downloads motherboard faq page on gigabyte s website 91
3 2 troubleshooting procedure 92
Ga ma770t ud3 us3 motherboard 92 92
If you encounter any troubles during system startup follow the troubleshooting procedure below to solve the problem 92
Appendix 93 93
If the procedure above is unable to solve your problem contact the place of purchase or local dealer for help or go to the support downloads technical service zone page to submit your question our customer service staff will reply you as soon as possible 93
4 regulatory statements 94
Our commitment to preserving the environment 94
Regulatory notices 94
Restriction of hazardous substances rohs directive statement 94
Waste electrical electronic equipment weee directive statement 94
Weee symbol statement 94
China restriction of hazardous substances table 95
Appendix 99 99
Contact us 99
Ga ma770t ud3 us3 motherboard 100 100
Gigabyte global service system 100
To submit a technical or non technical sales marketing question please link to http ggts gigabyte com tw then select your language to enter the system 100

Gigabyte GA-MA770T-US3 (rev.1.4) Инструкция по эксплуатации онлайн [2/100] 41749

Содержание

Похожие устройства
