─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No. Description Qty

1 Upright Frame 2

2 Left Angle Support 1

3 Right Angle Support 1

4 Elbow Pad Support Frame 2

5 Back Pad Support Frame 1

6 Right Chin-Up Bar 1

7 Left Chin-Up Bar 1

8 Base Frame 2

9 Cross Frame 1

10 Elbow Pad 2

11 Small Plate 2

12 Big Plate 2

13 Back Pad 1

14 Plug Φ32 4

15 Handle Grip Φ38*Φ32*550 2

16 Grip Φ32*175 6

17 Plug 50.8*76.2 2

19 Flat Washer Φ11*Φ23*2 42

20 Bolt Cap 2

21 Big Washer Φ11*Φ30*2 4

22 Button Head Cap Screw M10*75 8

23 Button Head Cap Screw M10*80 8

24 Button Head Cap Screw M10*100 4

25 Nylon lock Nut M10 20

26 Plug50.8 3

27 Button Head Cap Screw M10*72 6

28 Right Foot Cap 4

29 Left Foot Cap 4

30 Button Head Cap Screw M8*25 16

31 Flat Washer Φ9*Φ22*2 16

32 Hex Key S=6 1

33 Flat Wrench 17-19 1
