FAQs (Frequently Asked Questions)

Q: What differentiates passive matrix LCDs from active matrix LCDs?

A: An LCD is made with either a passive matrix or an active matrix display grid. An active matrix has

a transistor located at each pixel intersection, requiring less current to control the luminance of a

pixel. For this reason, the current in an active matrix display can be switched on and off more

frequently, improving the screen refresh time (your mouse pointer will appear to move more

smoothly across the screen, for example). The passive matrix LCD has a grid of conductors with

pixels located at each intersection in the grid.

Q: How does a TFT LCD Panel work?

A: On each column and row of the TFT LCD panel, a data source drive and a gate drive are attached,

respectively. The TFT drain of each cell is connected to the electrode. The molecular arrangement of

liquid crystal elements differ according to whether it is impressed with voltage or not. It varies the

direction of polarized light and the amount of light by letting it through different arrays of liquid

crystal elements. When two polarized filters are arranged vertically on a polarized light pole, the

light that passes through the upper polarized panel is turned 90 degrees along with the spiral

structure of the liquid crystal molecules and goes through the polarized filter at the bottom. When

impressed with voltage, liquid crystal molecules are arranged vertically from the original spiral

structure and the direction of the light is not turned through 90 degrees. In this case, light that

comes through the top polarized panel may not go through the polarized panel at the bottom.

Q: What are the advantages of TFT LCD compared with CRT?

A: In a CRT monitor, a gun shoots electrons and general light by colliding polarized electrons on

fluorescent glass. Therefore, CRT monitors basically operate with an analog RGB signal. A TFT LCD

monitor is a device that displays an input image by operating a liquid crystal panel. The TFT has a

fundamentally different structure than a CRT: Each cell has an active matrix structure and

independent active elements. A TFT LCD has two glass panels and the space between them is filled

with liquid crystal. When each cell is connected with electrodes and impressed with voltage, the

molecular structure of the liquid crystal is altered and controls the amount of inlet lighting to display

images. A TFT LCD has several advantages over a CRT, since it can be very thin and no flickering

occurs because it does not use the scanning method.

Q: Why is vertical frequency of 60Hz optimal for an LCD monitor?

A: Unlike a CDT monitor, the TFT LCD panel has a fixed resolution. For example, an XGA monitor

has 1024x3 (R, G, B) x 768 pixels and a higher resolution may not be available without additional

software processing. The panel is designed to optimize the display for a 65MHz dot clock, one of the

standards for XGA displays. Since the vertical/horizontal frequency for this dot clock is 60Hz/48kHz,

the optimum frequency for this monitor is 60Hz.

Q: What kind of wide-angle technology is available? How does it work?
