Connection Method of AV Input

1.Insert the external video cord into the yellow port of the AV exchange head, the left

sound track into the white port and the right sound track into the red port. Then plug

the AV exchange head in AV1/IN jack.

2.Insert the external video cord into the yellow port of the AV exchange head, the left

sound track into the white port and the right sound track into the red port. Then plug

the AV exchange head in AV2/IN jack.

3. Under VGA mode, plug the left sound cord into white port of

the exchange head, and right to the red. Then plug the AV

exchange head into the AV2/IN jack.

Connection Method of VGA Input

Plug the signal cord in VGA jack in PC, and tighten the screws to

keep good connection. Then plug another end of the cord in the

VGA jack of TV set and tighten screws as the same.

2. Basic operation methods of TV set

- Connect with power supply and turn on the power switch. While the TV is in

normal status, the power indicator is green. If it is red, please press Power

button on panel or control.

- Pull out telescopic antenna.

- Press CH-/CH+ to choose the desired channel.

- Adjust the sound volume of the TV signal.
