21
Power (222E2)
On mode (typical) 40W
Energy Consumption
(EnergyStar 5.0 test method)
AC Input Voltage at
100VAC +/-5VAC,
50Hz +/- 3Hz
AC Input Voltage at
115VAC +/-5VAC,
60Hz +/- 3Hz
AC Input Voltage at
230VAC +/-5VAC,
50Hz +/ -3Hz
Normal Operation (typical) 26.14W 25.93W 25.81W
Sleep (typical) 0.5W 0.5W 0.5W
Off 0.5W 0.5W 0.5W
Heat Dissipation* AC Input Voltage at
100VAC +/-5VAC,
50Hz +/ -3Hz
AC Input Voltage at
115VAC +/-5VAC,
60Hz +/ -3Hz
AC Input Voltage at
230VAC +/-5VAC,
50Hz +/ -3Hz
Normal Operation 89.215BTU 88.498BTU 88.089BTU
Sleep (typical) 1.706BTU 1.706BTU 1.706BTU
Off 1.706BTU 1.706BTU 1.706BTU
Power (222EL2)
On mode (typical) 19.7W
Energy Consumption
(EnergyStar 5.0 test method)
AC Input Voltage at
100VAC +/-5VAC,
50Hz +/- 3Hz
AC Input Voltage at
115VAC +/-5VAC,
60Hz +/- 3Hz
AC Input Voltage at
230VAC +/-5VAC,
50Hz +/ -3Hz
Normal Operation (typical) 17.02W 18.46W 18.52W
Sleep (typical) 0.5W 0.5W 0.5W
Off 0.5W 0.5W 0.5W
Heat Dissipation* AC Input Voltage at
100VAC +/-5VAC,
50Hz +/ -3Hz
AC Input Voltage at
115VAC +/-5VAC,
60Hz +/ -3Hz
AC Input Voltage at
230VAC +/-5VAC,
50Hz +/ -3Hz
Normal Operation 58.089BTU 63.003BTU 63.208BTU
Sleep (typical) 1.706BTU 1.706BTU 1.706BTU
Off 1.706BTU 1.706BTU 1.706BTU
Power LED indicator On mode: White, Standby/Sleep mode: White (blinking)
Power Supply Build-in, 100-240VAC, 50/60Hz
Dimension
Product with stand (WxHxD) 528.8 x 406 x 195mm
Product without stand
(WxHxD)
528.8 x 336.3 x 49mm
Box dimension (WxHxD) 570 x 465 x 155mm
Weight
Product with stand 4.25kg (222E2), 3.4kg (222EL2)
Product without stand 3.95kg (222E2), 3.1kg (222EL2)
Product with packaging 5.25kg (222E2), 4.4kg (222EL2)
