22
4.1 Resolution & Preset Modes
4.2 Automatic
PowerSaving
If you have VESA DPM compliance display card
or software installed in y
our PC, the monitor can
automatically reduce its power consumption when
not in use. If an input from a keyboard, mouse or
other input device is detected, the monitor will
'wake up' automatically. The following table shows
the power consumption and signaling of this
automatic power saving feature:
!
Maximum Resolution
For
192E2SB2
1366 x 768 at 60 Hz (analog input)
1366 x 768 at 60 Hz (digital input)
Recommended Resolution
For
192E2SB2
1366 x 768 at 60 Hz (digital input)
H. freq (kHz) Resolution V. freq (Hz)
31.47 720x400 70.09
31.47 640x480 59.94
37.50 640x480 75.00
37.88 800x600 60.32
46.88 800x600 75.00
48.36 1024x768 60.00
60.02 1024x768 75.03
63.89 1280x1024 60.02
79.98 1280x1024 75.03
47.71 1366x768 59.79
Power Management Definition
VESA
Mode
Video H-sync V-sync Power Used LED color
Active ON Yes Yes < 18W (typ.)) White
Sleep OFF No No < 0.5 W (typ.) White
(Blinking)
Switch Off OFF - - < 0.5 W (typ.) OFF
Note
This data is subject to change without notice.
The following setup is used to measure power
consumption on this monitor
.
Native resolution: 1366 x 768.
Contrast: 50%
Brightness: 200 nits
Color temperature: 6500k
