5
Connecting to your PC
Kensington anti-thief lock
AC power input
DVI-D input (available for selecting
model)
VGA input
Connect to PC
1. Connect the power cord to the back of
the montior firmly.
2. Turn off your computer and unplug its
po
wer cable.
3. Connect the monitor signal cable to the
video connector on the back of y
our
computer.
4. Plug the power cord of your computer
and y
our monitor into a nearby outlet.
5. T
urn on your computer and monitor. If
the monitor displays an image, installation
is complete.
2.2 Operating the monitor
Front view product description
: To access OSD menu.
: Return to previous OSD level.
: Change to 4:3 display.
: To switch monitor’s power on and off.
: To adjust the OSD menu.
: To change the signal input.
: SmartImage Lite. There are 3 modes
to be selected: Standard, Internet and
Game.
