23
4.1 Resolution & Preset Modes
4.2 Automatic PowerSaving
If you have VESA DPM compliance display card
or software installed in your PC, the monitor can
automatically reduce its power consumption when
not in use. If an input from a keyboard, mouse or
other input device is detected, the monitor will
'wake up' automatically. The following table shows
the power consumption and signaling of this
automatic power saving feature:
Maximum Resolution
For
232E2/232EL2
1920 x 1080 at 60 Hz (analog input)
1920 x 1080 at 60 Hz (digital input)
Recommended Resolution
For
232E2/232EL2
1920 x 1080 at 60 Hz (digital input)
H. freq (kHz) Resolution V. freq (Hz)
31.47 640x480 59.94
37.88 800x600 60.32
48.36 1024x768 60.00
54.00 1152x864 60.00
44.77 1280x720 59.86
47.78 1280x768 59.87
49.70 1280x800 59.81
60.00 1280x960 60.00
63.89 1280x1024 60.02
47.71 1360x768 60.02
55.47 1440x900 59.90
55.94 1440x900 59.89
75.00 1600x1200 60.00
64.67 1680x1050 59.88
65.29 1680x1050 59.95
66.59 1920x1080 59.93
74.04 1920x1200 59.95
67.50 1920x1080 60.00
Power Management Definition
VESA
Mode
Video H-sync V-sync Power Used LED color
Active ON Yes Yes 232E2< 41.8W (typ.)
232EL2< 28.8W (typ.)
White
Sleep OFF No No < 0.5 W (typ.) White
(Blinking)
Switch Off OFF - - < 0.5 W (typ.) OFF
Note
This data is subject to change without notice.
The following setup is used to measure power
consumption on this monitor.
Native resolution: 1920x1080.
Contrast: 50%
Brightness: 300 nits (232E2); 250 nits (232EL2)
Color temperature: 6500k
