47
Q7: How should I clean the LCD surface?
Ans.: For normal cleaning, use a clean, soft cloth.
For extensive cleaning, please use isopropyl
alcohol. Do not use other solvents such as
ethyl alcohol, ethanol, acetone, hexane, etc.
Q8: Can I change the color setting of my
monitor?
Ans.: Yes, you can change your color setting
through OSD control as the following
procedures,
• Press "OK" to show the OSD (On Screen
Display) menu
• Press "Down Arrow" to select the option
"Color" then press "OK" to enter color
setting, there are three settings as below.
1. Color Temperature; The 2 settings are
6500K, and 9300K.
2. sRGB; this is a standard setting for
ensuring correct exchange of colors
between different device (e.g. digital
cameras, monitors, printers, scanners, etc)
3. User Define; the user can choose his/her
preference color setting by adjusting red,
green blue color.
Note:
A measurement of the color of light radiated by an
object while it is being heated. This measurement
is expressed in terms of absolute scale, (degrees
Kelvin). Lower Kevin temperatures such as 2004K
are red; higher temperatures such as 9300K are
blue. Neutral temperature is white, at 6504K.
Q9: Can the Philips LCD Monitor be mounted
on the wall?
Ans.: Yes. Philips LCD monitors have this optional
feature. Four standard VESA mount holes
on the rear cover allows the user to
mount the Philips monitor on most of the
VESA standard arms or accessories. We
recommend you to contact your Philips
sales representative for more information.
Q10: Can I connect my LCD monitor to any PC,
workstation or Mac?
Ans.: Yes. All Philips LCD monitors are fully
compatible with standard PCs, Macs and
workstations. You may need a cable adapter
to connect the monitor to your Mac
system. Please contact your Philips sales
representative for more information.
Q11: Are Philips LCD monitors Plug-and- Play?
Ans.: Yes, the monitors are Plug-and-Play
compatible with Windows 7/Vista/XP/NT,
Mac OSX, Linux
Q12: What kind of wide-angle technology is
available?
Ans.: Currently, the IPS type panels offer the best
Contrast Ratio, compared to MVA, or PVA
technologies. TN panels have improved over
the years, but IPS panel still gives superior
results over TN panel.
