Phonebook Table
Name
Shows the name corresponding to the phone number
Number
Shows the phone number
Ring Type
Shows the ring type of the incoming call.
Group
Shows the group of the contact
Notice: the maximum capability of the phonebook is 500 items, you can select
many or a contact to add to group and add to blacklist, and delete many or a
contact, and delete all contacts.
Add Contact List
Name
Specify the name corresponding to the phone
number
Office Number
Specify the office number
Mobile Number
Specify the mobile number
Other Number
Specify the other number
Ring Type
Specify the ring type for the phone number
Line
Specify the sip line for the each number
Group setting
Select the group from the unselected group to
selected list for the contact; you can select many
groups for the contact.
Notice: the add button for adding a new contact, the modify button for
modifying the added contact, the clear all button for clear all input information
of the contact
Group Option
Group
Select the added groups, then modify or delete and
so on
Name
Input the name of the group, then click the add
button, you can add a new group.
Ring Type
Specify the ring type for the group as adding a new
group
Import Contact List
Select File
Click the browse button to select the phonebook file
that you want to import, than click update button,
the phonebook file selected will be added to the
phone.
Export Contact File
Export XML
Click export xml button to export phonebook file of
xml model
Export CSV
Click export xml button to export phonebook file of
csv model
Export VCF
Click export xml button to export phonebook file of
