configurations are the same, the auto provision would
stop here. If the endpoints confirm the configuration
by Digest method, the endpoints wouldn‟t upgrade
configuration unless the configuration in the server is
different with the running configuration.
CPE Serial Number
Show CPE Serial Number
User
Specify FTP/HTTP/HTTPS server Username. System
will use anonymous if username keep blank.
Password
Specify FTP/HTTP/HTTPS server Password.
Config Encrypt Key
Input the Encrypt Key, if the configuration file is
encrypted.
Common Config
Encrypt Key
Input the Common Encrypt Key, if the Common
Configuration file is encrypted
Save Autoprovision
Information
Save the username and password authentication
message of http/https/ftp and input ID message in the
phone until the URL in the server changes
DHCP Option
Setting
DHCP Option
Setting
Specify DHCP Option. DHCP option supports DHCP
custom option and DHCP option 66 and DHCP option
43 to obtain the parameters. You could choose one
method among them，the default is DHCP option
disable.
Custom DHCP
Option
A valid Custom DHCP Option is from 128 to 254. The
Custom DHCP Option must be in accordance with the
one defined in the DHCP server.
Plug and Play
Enable PnP
Enable PnP by selecting it, than the phone will send
SIP SUBSCRIBE messages to a multicast address
when it boots up. Any SIP server understanding that
message will reply with a SIP NOTIFY message
containing the Auto Provisioning Server URL where
the phones can request their configuration.
PnP Server
Specify the PnP Server
PnP Port
Specify the PnP Server
PnP Transport
Specify the PnP Transfer protocol
PnP Interval
Specify the Interval time, unit is hour
Phone Flash
Server Address
Set FTP/TFTP/HTTP/HTTPS server IP address for
auto update. The address can be IP address or Domain
name with subdirectory.
Config File Name
Set configuration file‟s name which need to update.
System will use MAC as config file name if config file
