Chapter 1 Quick Start RIGOL
RSA5000 User's Guide 1-9
Sets other system parameters based on the current marker
value.
Indicates the special functions of the marker, such as noise
marker, N dB bandwidth measurement, and frequency counter.
Sets the sweep parameters.
Sets the sweep/measurement mode to be continuous.
Sets the sweep/measurement mode to be single.
Sets the trigger source and its related parameters.
Selects the working mode of the spectrum analyzer.
Sets the parameters for the selected working mode.
Selects and controls the measurement function
[2]
.
Sets the parameters
[2]
for the selected measurement function.
Searches for signals automatically within full frequency range.
Restores the system to factory settings or user-defined state.
Sets the system parameters.
Recalls the files.
Manages the files.
Saves the files.
User-defined shortcut key.
Provides quick save function.
Note
[1]
: This function is only available for RSA5065-TG/RSA5032-TG.
Note
[2]
: This function is only available for the instrument installed with RSA5000-AMK.
