24 | English

1 619 929 797 | (3.2.09) Bosch Power Tools

Changing the Tool

The dust protection cap 3 largely prevents the

entry of drilling dust into the tool holder during

operation. When inserting the tool, take care

that the dust protection cap 3 is not damaged.

f A damaged dust protection cap should be

changed immediately. We recommend hav-

ing this carried out by an after-sales serv-

ice.

Inserting SDS-plus Drilling Tools (see figure E)

The SDS-plus drill chuck allows for simple and

convenient changing of drilling tools without the

use of additional tools.

– Clean and lightly grease the shank end of the

tool.

– Insert the tool in a twisting manner into the

tool holder until it latches itself.

– Check the latching by pulling the tool.

As a requirement of the system, the SDS-plus

drilling tool can move freely. This causes a cer-

tain radial run-out at no-load, which has no ef-

fect on the accuracy of the drill hole, as the drill

bit centres itself upon drilling.

Removing SDS-plus Drilling Tools

(see figure F)

– Push back the locking sleeve 4 and remove

the tool.

Inserting Drilling Tools without SDS-plus

Note: Do not use tools without SDS-plus for

hammer drilling! Tools without SDS-plus and

their drill chucks are damaged by hammer drill-

ing.

– Insert a key type drill chuck 18 (see “Chang-

ing the Key Type Drill Chuck”, page 23).

– Open the key type drill chuck 18 by turning

until the tool can be inserted. Insert the tool.

– Insert the chuck key into the corresponding

holes of the key type drill chuck 18 and clamp

the tool uniformly.

– Set the selector switch 8 to the “Drilling”

symbol.

Removing Drilling Tools without SDS-plus

– Turn the sleeve of the key type drill chuck 18

with the drill chuck key in anticlockwise di-

rection until the drilling tool can be removed.

Dust Extraction with the Dust Extrac-

tion Attachment (Accessory)

f Dusts from materials such as lead-containing

coatings, some wood types, minerals and

metal can be harmful to one’s health. Touch-

ing or breathing-in the dusts can cause aller-

gic reactions and/or lead to respiratory infec-

tions of the user or bystanders.

Certain dusts, such as oak or beech dust, are

considered as carcinogenic, especially in

connection with wood-treatment additives

(chromate, wood preservative). Materials

containing asbestos may only be worked by

specialists.

– Use dust extraction whenever possible.

– Provide for good ventilation of the work-

ing place.

– It is recommended to wear a P2 filter-

class respirator.

Observe the relevant regulations in your

country for the materials to be worked.

Mounting the Dust Extraction Attachment

(see figure G)

For dust extraction, the dust extraction attach-

ment (accessory) is required. When drilling, the

dust extraction attachment retracts so that the

attachment head is always close to the surface

at the drill hole.

– Press the button for depth stop adjustment 9

and remove the depth stop 1. Press button 9

again and insert the dust extraction attach-

ment into the auxiliary handle 16 from the

front.

– Connect an extraction hose (diameter

19 mm, accessory) to the extraction sleeve

20 of the dust extraction attachment.

The vacuum cleaner must be suitable for the ma-

terial being worked.

When vacuuming dry dust that is especially det-

rimental to health or carcinogenic, use a special

vacuum cleaner.

OBJ_BUCH-518-002.book Page 24 Tuesday, February 3, 2009 12:02 PM
