26 | English
1 619 929 797 | (3.2.09) Bosch Power Tools
Setting the Speed/Impact Rate
The speed/impact rate of the switched on pow-
er tool can be variably adjusted, depending on
how far the On/Off switch 7 is pressed.
Light pressure on the On/Off switch 7 results in
low speed/impact rate. Further pressure on the
switch increases the speed/impact rate.
Safety Clutch
f If the tool insert becomes caught or
jammed, the drive to the drill spindle is in-
terrupted. Because of the forces that occur,
always hold the power tool firmly with both
hands and provide for a secure stance.
f If the power tool jams, switch the machine
off and loosen the tool insert. When switch-
ing the machine on with the drilling tool
jammed, high reaction torques can occur.
Temperature Control Indicator
The red LED of the temperature control indica-
tor 13 signals that the battery or the electronics
of the power tool (when the battery is inserted)
are not within the optimum temperature range.
In this case, the power tool will not operate at
full capacity.
Temperature control of the battery:
– The red LED 13 lights up continuously after
inserting the battery into the charger: The
battery is not within the charging tempera-
ture range between 0°C and 45 °C and can-
not be charged.
– The red LED 13 flashes when pushing button
15 or pressing the On/Off switch 7 (when the
battery is inserted): The battery is not wihin
the temperature range for operation of
–10°C to +60°C.
– For battery temperatures over 70 °C, the
power tool switches off until the battery is in
the optimal temperature range again.
Temperature control of the power tool electron-
ics:
– The red LED 13 lights up continuously when
pressing the On/Off switch 7: The tempera-
ture of the machine's electronics is below
5 °C or above 75 °C.
– At a temperature above 90 °C , the electron-
ics of the power tool switch off until the tem-
perature is within the allowable temperature
range again.
Working Advice
Vibration Damper
The integrated vibration damper reduces occur-
ring vibrations.
The soft grip handle increases the safety against
slipping off and thus provides for a better grip
and handling of the power tool.
– For optimum use of the vibration-dampening
feature, hold the power tool in the upper
gripping area.
Inserting Screwdriver Bits (see figure J)
f Apply the power tool to the screw/nut only
when it is switched off. Rotating tool inserts
can slip off.
To work with screwdriver bits, a universal bit
holder 26 with SDS-plus shank (accessory) is re-
quired.
– Clean the shank end of the adapter shank
and apply a light coat of grease.
– Insert the universal bit holder with a turning
motion into the tool holder until it automati-
cally locks.
– Check the locking effect by pulling the uni-
versal bit holder.
– Insert a screwdriver bit into the universal bit
holder. Use only screwdriver bits that match
the screw head.
– To remove the universal bit holder, pull the
locking sleeve 4 toward the rear and remove
the universal bit holder 26 out of the tool
holder.
OBJ_BUCH-518-002.book Page 26 Tuesday, February 3, 2009 12:02 PM
