¾ PoE Ports (1-4): These ports support PoE function which

integrates power and data onto one Ethernet cable. Once

the device you connect to the Switch is identified, the Switch

will supply power through the PoE port, and then you can

use it as a 10/100/1000Mbps Auto-Negotiation RJ45

Ethernet port. The working status can be indicated by the

corresponding LEDs on the front panel.

¾ Ethernet Ports (1-8): Besides the 4 PoE ports, the

TL-SG1008P Switch is also equipped with the other four

10/100/1000Mbps Auto-Negotiation RJ45 ports without PoE

function. Once the network devices are connected to these

8 ports through the network cable, the Switch will make

them plug and play according to the Auto-MDI/MDIX

detection. The working status can be indicated by the

corresponding LEDs on the front panel.

Note

Make sure the PDs you connected to the Switch are compliant

with IEEE802.3af.
