6
Name Status Indication
On
(green)
The Switch is powered on.
Power
Off The Switch is powered off.
On
(green)
There is a PoE PD connected to the port,
which supply power successfully.
Flashing
(green)
The PoE power circuit may be in short or
the power current may be overloaded.
PoE
ports
(port-1~
port-4)
Off
No PD is connected to the corresponding
port，or no power is supplied according to
the power limits of the port.
On
(red)
The power of all the connected PoE ports
is >=46W. No power may be supplied if
additional PDs are connected.
Flashing
(red)
The power of all the connected PoE ports
is >=53W.
PoE
MAX
Off
The power of all the connected PoE ports
is <46W, or there is No PD connected to
the corresponding port.
On
(green)
A valid link is established on the port.
Flashing
(green)
Data transmitting or receiving on
corresponding port.
Link/Act
(port-1~
port-8)
Off
No device is connected to the
corresponding port.
On
(green)
There is a 100Mbps device connected to
the corresponding port.
100Mbps
(port-1~
port-8)
Off
There is a 10Mbps device connected to the
corresponding port, or there is no device
connected to the corresponding port.
