Motherboard
GA-8I865GVM-775/
GA-8I865GVMF-775
Sep. 21, 2004
Sep. 21, 2004
Motherboard
GA-8I865GVM-775/GA-8I865GVMF-775
Содержание
- Ga 8i865gvm 775 ga 8i865gvmf 775 1
- User s manual 1
- Copyright 3
- Notice 3
- Product manual classification 3
- Chapter 1 hardware installation 4
- Chapter 2 bios setup 27 4
- Ga 8i865gvm 775 ga 8i865gvmf 775 motherboard layout block diagram 4
- Table of contents 4
- Chapter 3 drivers installation 45 5
- Chapter 4 appendix 49 5
- Ga 8i865gvm 775 ga 8i865gvmf 775 motherboard layout 6
- Ga 8i865gvm 775 or ga 8i865gvmf 775 6
- Only for ga 8i865gvmf 775 6
- Block diagram 7
- 1 considerations prior to installation 9
- Chapter 1hardware installation 9
- English 9
- Installation notices 9
- Instances of non warranty 9
- Preparing your computer 9
- 2 feature summary 10
- English 10
- 3 1 installation of the cpu 11
- 3 installation of the cpu and heatsink 11
- English 11
- 3 2 installation of the heatsink 12
- English 12
- 4 installation of memory 13
- English 13
- Dual channel ddr 14
- English 14
- 5 installation of expansion cards 15
- English 15
- 6 i o back panel introduction 16
- Com a serial port 16
- English 16
- Lan port 16
- Line in 16
- Line out 16
- Mic in 16
- Parallel port 16
- Ps 2 keyboard and ps 2 mouse connector 16
- Usb port 16
- Vga port 16
- 7 connectors introduction 17
- English 17
- 2 atx_12v atx power connector 18
- English 18
- Ga 8i865gvm f 775 motherboard 18 18
- With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector please make sure that all components and devices are properly installed align the power connector with its proper location on the motherboard and connect tightly the atx_12v power connector mainly supplies power to the cpu if the atx_12v power connector is not connected the system will not start caution please use a power supply that is able to handle the system voltage requirements it is recommended that a power supply that can withstand high power consumption be used 300w or greater if a power supply is used that does not provide the required power the result can lead to an unstable system or a system that is unable to start please remove the sticker on the motherboard before plugging in while the atx power supplier is 24 pins otherwise please do not remove it 18
- 4 cpu_fan sys_fan cooler fan power connector 19
- English 19
- Fdd fdd connector 19
- An ide device connects to the computer via an ide connector one ide connector can connect to one ide cable and the single ide cable can then connect to two ide devices hard drive or optical drive if you wish to connect two ide devices please set the jumper on one ide device as master and the other as slave for information on settings please refer to the instructions located on the ide device 20
- English 20
- Ga 8i865gvm f 775 motherboard 20 20
- Ide1 ide2 ide connector 20
- Sata0 sata1 serial ata connector 20
- Serial ata can provide 150mb s transfer rate please refer to the bios setting for the serial ata and install the proper driver in order to work properly 20
- Bat battery 21
- English 21
- Hardware installation 21 21
- Pwr_led 21
- Pwr_led is connect with the system power indicator to indicate whether the system is on off it will blink when the system enters suspend mode 21
- English 22
- F_panel front panel jumper 22
- Ga 8i865gvm f 775 motherboard 22 22
- Please connect the power led pc peaker reset switch and power switch etc of your chassis front panel to the f_panel connector according to the pin assignment below 22
- Cd_in cd in connector 23
- Connect cd rom or dvd rom audio out to the connector 23
- English 23
- F_audio front audio panel connector 23
- Hardware installation 23 23
- If you want to use front audio connector you must remove 5 6 9 10 jumper in order to utilize the front audio header your chassis must have front audio connector also please make sure the pin assigment on the cable is the same as the pin assigment on the mb header to find out if the chassis you are buying support front audio connector please contact your dealer please note you can have the alternative of using front audio connector or of using rear audio connector to play sound 23
- Be careful with the polarity of the front usb connector check the pin assignment carefully while you connect the front usb cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional front usb cable please contact your local dealer 24
- English 24
- F_ usb1 f_usb2 front usb connector 24
- Ga 8i865gvm f 775 motherboard 24 24
- Spdif spdif out connector 24
- The spdif output is capable of providing digital audio to external speakers or compressed ac3 data to an external dolby digital decoder use this feature only when your stereo system has digital input function be careful with the polarity of the spdif connector check the pin assignment carefully while you connect the spdif cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional spdif cable please contact your local dealer 24
- Be careful with the polarity of the comb connector check the pin assignment carefully while you connect the comb cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional comb cable please contact your local dealer 25
- Comb com b connector 25
- English 25
- F1_1394 f2_1394 ieee1394 connector 25
- Hardware installation 25 25
- Only for ga 8i865gvmf 775 25
- Serial interface standard set by institute of electrical and electronics engineers which has features like high speed high bandwidth and hot plug be careful with the polarity of the ieee1394 connector check the pin assignment carefully while you connect the ieee1394 cable incorrect connection between the cable and connector will make the device unable to work or even damage it for optional ieee1394 cable please contact your local dealer 25
- Be careful with the polarity of the ir connector while you connect the ir please contact your nearest dealer for optional ir device 26
- Clr_cmos clear cmos 26
- English 26
- Ga 8i865gvm f 775 motherboard 26 26
- You may clear the cmos data to its default values by this jumper to clear cmos temporarily short 1 2 pin default doesn t include the shunter to prevent from improper use this jumper 26
- Chapter 2 bios setup 27
- Control keys 27
- English 27
- Main menu 27
- Status page setup menu option page setup menu 27
- Advanced bios features 28
- English 28
- Fail safe defaults indicates the value of the system parameters which the system would be in safe configuration 28
- Frequency voltage control 28
- Ga 8i865gvm f 775 motherboard 28 28
- If you can t find the setting you want please press ctrl f1 to search the advanced option hidden 28
- Integrated peripherals 28
- Load fail safe defaults 28
- Pc health status 28
- Pnp pci configuration 28
- Power management setup 28
- Standard cmos features 28
- The main menu for example bios ver e2 28
- This setup page includes all onboard peripherals 28
- This setup page includes all the configurations of pci pnp isa resources 28
- This setup page includes all the items in standard compatible bios 28
- This setup page includes all the items of award special enhanced features 28
- This setup page includes all the items of green function features 28
- This setup page is control cpu clock and frequency ratio 28
- This setup page is the system auto detect temperature voltage fan speed 28
- To accept or enter the sub menu 28
- English 29
- 1 standard cmos features 30
- Access mode use this to set the access mode for the hard drive the four options are chs lba large auto default auto hard drive information should be labeled on the outside drive casing enter the appropriate option based on this information 30
- Cylinder number of cylinders 30
- Day the day from 1 to 31 or the maximum allowed in the month 30
- English 30
- Ga 8i865gvm f 775 motherboard 30 30
- Head number of heads 30
- Ide channel 0 1 master slave ide device setup you can use one of three methods auto allows bios to automatically detect ide devices during post default value none select this if no ide devices are used and the system will skip the automatic detection step and allow for faster system start up manual user can manually input the correct settings 30
- Ide channel 0 master slave ide channel 1 master slave 30
- Ide hdd auto detection press enter to select this option for automatic device detection 30
- Landing zone landing zone 30
- Month the month jan through dec 30
- Precomp write precomp 30
- The time is calculated base on the 24 hour military time clock for example 1 p m is 13 00 00 30
- Week the week from sun to sat determined by the bios and is display only 30
- Year the year from 1999 through 2098 30
- Base memory 31
- Drive a drive b 31
- English 31
- Extended memory 31
- Floppy 3 mode support for japan area 31
- Halt on 31
- Memory 31
- Total memory 31
- 2 advanced bios features 32
- English 32
- First second third boot device 32
- Hard disk boot priority 32
- Password check 32
- Cpu hyper threading 33
- English 33
- Limit cpuid max to 3 33
- On chip frame buffer size 33
- 3 integrated peripherals 34
- Auto when there is no device to be plugged in ide1 or ide2 sata controller will remap to ide controller default value 34
- Disabled disable onboard 1st channel ide port 34
- Disabled disable onboard 2nd channel ide port 34
- Disabled disable onboard seria ata function 34
- Enabled enable onboard 1st channel ide port default value 34
- Enabled enable onboard 2nd channel ide port default value 34
- English 34
- Ga 8i865gvm f 775 motherboard 34 34
- Manual set sata mode manually from sata port0 configure as item 34
- On chip primary pci ide 34
- On chip sata 34
- On chip secondary pci ide 34
- Only for ga 8i865gvmf 775 34
- Ac97 audio 35
- English 35
- Onboard h w 1394 35
- Onboard h w lan 35
- Onboard lan boot rom 35
- Sata port0 configure as 35
- Sata port1 configure as 35
- Usb 2 controller 35
- Usb controller 35
- Usb keyboard support 35
- Usb mouse support 35
- Ecp mode use dma 36
- English 36
- Onboard parallel port 36
- Onboard serial port 1 36
- Onboard serial port 2 36
- Parallel port mode 36
- Power on function 36
- Uart mode select 36
- Ur2 duplex mode 36
- 4 power management setup 37
- Ac back function 37
- Acpi suspend type 37
- English 37
- Modemringon wakeonlan 37
- Off by power button 37
- Pme event wake up 37
- Power led in s1 state 37
- 5 pnp pci configurations 38
- English 38
- Pci 1 irq assignment 38
- Pci 2 irq assignment 38
- Pci 3 irq assignment 38
- Resume by alarm 38
- 6 pc health status 39
- Bios setup 39 39
- Current cpu system fan speed rpm 39
- Current cpu system temperature 39
- Current voltage v vcore 3 v 5v 12v ddr25v 39
- Detect cpu system fan speed status automatically 39
- Detect cpu system temperature automatically 39
- Detect system s voltage status automatically 39
- English 39
- 7 frequency voltage control 40
- Cpu clock ratio 40
- English 40
- Memory frequency for 40
- Memory frequency mhz 40
- 8 load fail safe defaults 41
- 9 load optimized defaults 41
- Bios setup 41 41
- English 41
- Fail safe defaults contain the most appropriate values of the system parameters that allow minimum system performance 41
- Selecting this field loads the factory defaults for bios and chipset features which the system automatically detects 41
- 10 set supervisor user password 42
- English 42
- Ga 8i865gvm f 775 motherboard 42 42
- When you are prompted to enter password a message password disabled will appear to confirm the password being disabled once the password is disabled the system will boot and you can enter setup freely the bios setup program allows you to specify two separate passwords supervisor password and a user password when disabled anyone may access all bios setup program function when enabled the supervisor password is required for entering the bios setup program and having full configuration fields the user password is required to access only basic items if you select system at password check in advance bios features menu you will be prompted for the password every time the system is rebooted or any time you try to enter setup menu if you select setup at password check in advance bios features menu you will be prompted only when you try to enter setup 42
- 11 save exit setup 43
- 12 exit without saving 43
- Bios setup 43 43
- English 43
- Type y will quit the setup utility and save the user setup value to rtc cmos type n will return to setup utility 43
- Type y will quit the setup utility without saving to rtc cmos type n will return to setup utility 43
- English 44
- 1 install chipset drivers 45
- Chapter 3drivers installation 45
- English 45
- 2 software application 46
- 3 software information 46
- English 46
- 4 hardware information 47
- 5 contact us 47
- English 47
- English 48
- 1 1 xpress recovery introduction 49
- 1 unique software utilities 49
- Chapter 4 appendix 49
- English 49
- English 50
- F9 for xpress recovery 50
- English 51
- Execute backup utility 51
- Execute restore utility 51
- Exit and restart 51
- Please input a 4 16 character long password a z or 0 9 or press esc to exit 51
- Press b to backup your system or esc to exit 51
- Press r to restore your system back to factory default or press esc to exit 51
- Remove backup image 51
- Remove backup image are you sure y n 51
- Set password 51
- This program will recover your system to factory default 51
- 1 2 flash bios method introduction 52
- Before you begin 52
- English 52
- Method 1 q flas 52
- Part one 52
- Updating bios with q flas 52
- Utility 52
- Utility on dual bios motherboards 52
- Action bar 53
- Appendix 53 53
- Contains the names of eight tasks and two item showing information about the bios rom type blocking a task and pressing enter key on your keyboard to enable execution of the task 53
- Contains the names of four actions needed to operate the q flash dual bios utility pressing the buttons mentioned on your keyboards to perform these actions 53
- Contains the names of four tasks blocking a task and pressing enter key on your keyboard to enable execu tion of the task 53
- Dual bios 53
- Dual bios utility bar 53
- Dual bios utility screen 53
- English 53
- Entering the q flas 53
- Exploring the q flas 53
- Q flas 53
- Step 2 press f8 button on your keyboard and then y button to enter the dual bios q flash utility 53
- Step1 to use q flash utility you must press del in the boot screen to enter bios menu 53
- Task menu for 53
- Task menu for dual bios utility 53
- Task menu for q flash utility 53
- The q flash dual bios utility screen consists of the following key components 53
- Utility 53
- Utility title 53
- After bios file is read you ll see a confirmation dialog box asking you are you sure to update bios 54
- After pressing enter you ll then see the progress of reading the bios file from the floppy disk 54
- Bios file in the floppy 54
- Do not trun off power or 54
- English 54
- Ga 8i865gvm f 775 motherboard 54 54
- If you want to save the current bios for backup purpose you can begin step 1 with save main bios to floppy item 54
- In this example we only download one bios file to the floppy disk so only one bios file 54
- Knxpu fba is listed 54
- Move to the bios file you want to flash and press enter 54
- Please confirm again you have the correct bios file for your motherboard 54
- Press arrow buttons on your keyboard to move the light bar to load main bios from floppy item in the q flash menu and press enter button later you will see a box pop up showing the bios files you previously downloaded to the floppy disk 54
- Reset your system at this 54
- This section tells you how to update bios using the q flash utility as described in the before you begin section above you must prepare a floppy disk having the bios file for your motherboard and insert it to your computer if you have already put the floppy disk into your system and have entered the q flash utility please follow the steps below to flash bios 54
- Using the q flas 54
- Utility 54
- After system reboots you may find the bios version on your boot screen becomes the one you flashed 55
- Appendix 55 55
- Becomes fab after 55
- English 55
- Please do not take out the floppy disk when it begins flashing bios 55
- Press any keys to return to the q flash menu when the bios updating procedure is completed 55
- Press esc and then y button to exit the q flash utility the computer will restart automatically after you exit q flash 55
- Press y button on your keyboard after you are sure to update bios then it will begin to update bios the progress of updating bios will be displayed 55
- The bios file 55
- To flash the backup bios too 55
- Updating 55
- You can repeat step 1 to 55
- English 56
- Ga 8i865gvm f 775 motherboard 56 56
- Part two 56
- Press del to enter bios menu after system reboots when you are in bios menu move to load fail safe defaults item and press enter to load bios fail safe defaults normally the system redetects all devices after bios has been upgraded therefore we highly recommend reloading the bios defaults after bios has been upgraded 56
- Press y on your keyboard to load defaults 56
- Press y on your keyboard to save and exit 56
- Select save exit setup item to save the settings to cmos and exit the bios menu system will reboot after you exit the bios menu the procedure is completed 56
- This part guides users of single bios motherboards how to update bios using the q flas 56
- Updating bios with q flas 56
- Utility 56
- Utility on single bios motherboards 56
- Action bar 57
- After bios file is read you ll see a confirmation dialog box asking you are you sure to update bios 57
- Appendix 57 57
- Bios file in the floppy disk 57
- Contains the names of four actions needed to operate the q flash utility pressing the buttons mentioned on your keyboards to perform these actions 57
- Contains the names of three tasks blocking a task and pressing enter key on your keyboard to enable execution of the task 57
- Do not trun off power or reset your system at 57
- English 57
- Exploring the q flas 57
- If you want to save the current bios for backup purpose you can begin step 1 with save bios to floppy item 57
- Move to the bios file you want to flash and press enter in this example we only download one bios file to the floppy disk so only one bios file 8ge800 f4 is listed 57
- Please confirm again you have the correct bios file for your motherboard 57
- Please do not take out the floppy disk when it begins flashing bios 57
- Press arrow buttons on your keyboard to move the light bar to update bios from floppy item in the q flash menu and press enter button later you will see a box pop up showing the bios files you previously downloaded to the floppy disk 57
- Q flas 57
- Task menu for q flas 57
- Task menu for q flash utility 57
- The q flashbios utility screen consists of the following key components 57
- This section tells you how to update bios using the q flash utility as described in the before you begin section above you must prepare a floppy disk having the bios file for your motherboard and insert it to your computer if you have already put the floppy disk into your system and have entered the q flash utility please follow the steps below to flash bios 57
- This stage 57
- Using the q flas 57
- Utility 57
- Utility bar 57
- Utility screen 57
- After system reboots you may find the bios version on your boot screen becomes the one you flashed 58
- At this stage 58
- Congratulation you have updated bios successfully 58
- Do not trun off power or reset your system 58
- English 58
- Ga 8i865gvm f 775 motherboard 58 58
- Press any keys to return to the q flash menu when the bios updating procedure is completed 58
- Press del to enter bios menu after system reboots and load bios fail safe defaults see how to load bios fail safe defaults please kindly refer to step 6 to 7 in part one 58
- Press esc and then y button to exit the q flash utility the computer will restart automatically after you exit q flash 58
- Press y button on your keyboard after you are sure to update bios then it will begin to update bios the progress of updating bios will be shown at the same time 58
- The bios file becomes f4 after updating 58
- English 59
- Method 2 bio 59
- Methods and steps 59
- Utility 59
- English 60
- 1 3 2 4 5 channel audio function introduction 61
- English 61
- Stereo speakers connection and settings 61
- Channel audio setup 62
- English 62
- Channel audio setup 63
- English 63
- English 64
- Spdif output device optional device 64
- 2 troubleshooting 65
- English 65
- English 66
- English 67
- English 68
- English 69
- English 70
- Appendix 71 71
- Contact us 71
- English 71
- English 72
- Ga 8i865gvm f 775 motherboard 72 72
Похожие устройства
- HTC Desire C Black Инструкция по эксплуатации
- Beko WMD 25080 R Инструкция по эксплуатации
- Ballu OH-39 /9 секций Инструкция по эксплуатации
- Gigabyte GA-8I865GVM-775 Инструкция по эксплуатации
- HTC Windows Phone 8S Blue Инструкция по эксплуатации
- BBK LT3221SU Инструкция по эксплуатации
- Ballu OH-39 /7 секций Инструкция по эксплуатации
- Gigabyte GA-8I865GMK-775 (rev. 2.0) Инструкция по эксплуатации
- Tefal TL 2000 Инструкция по эксплуатации
- HTC Windows Phone 8S Black Инструкция по эксплуатации
- Ballu OH-39 /11 секций Инструкция по эксплуатации
- Gigabyte GA-8I865GMK-775 (rev. 1.0) Инструкция по эксплуатации
- Neff K6604X6 Инструкция по эксплуатации
- Huawei Ascend G510 Black Инструкция по эксплуатации
- Ballu OH-04 /7 секций Инструкция по эксплуатации
- Hyundai H-LCDVD705 Инструкция по эксплуатации
- Transcend TS4GJFV30 Инструкция по эксплуатации
- Ballu OH-04 /9 секций Инструкция по эксплуатации
- Novex NFP-2002 Инструкция по эксплуатации
- Gigabyte GA-8I865GME-775-RH-AS (rev. 3.9) Инструкция по эксплуатации
