1. Before installation (Before finishing installation, do not throw the attached parts installation needs)

NOTE

All Wiring of this installation must comply with NATIONAL, STATE AND LOCAL REGULATIONS. These instructions

do not cover all variations for every kind of installation circumstance. Should further information be desired or should particular

problems occur, the matter should be referred to your local distributor.

WARNING

BE SURE TO READ THESE INSTRUCTIONS CAREFULLY BEFORE BEGINNING INSTALLATION. FAILURE TO FOLLOW

THESE INSTRUCTIONS COULD CAUSE SERIOUS INJURY OR DEATH, EQUIPMENT MALFUNCTION AND/OR

PROPERTY DAMAGE.

Confirm the way to move the unit to the installation place.

Before moving the unit to the installation place, do not remove their packages. When having to remove the package, use

a soft material or protection board with rope to lift the unit assembly to avoid unit damage or bumping a scrape.

2. Selecting the installation place

(1) The chosen installation place should meet the following requirements and get the users consent.

Place ensures ideal airflow distribution.

The passage of airflow has no obstacles.

When importing outside air, it should be imported directly from outdoors. (if the pipe can not be extended, it also can not

be imported from top)

Place ensures enough space for maintenance.

The pipe length between indoor and outdoor unit is in the permitted limit (referring to outdoor unit installation part).

The indoor unit, outdoor unit, electric wire and connection wire is at least 1m away from television and radio. This is to

avoid the image disturbance and noise caused by the above-mentioned home appliance. (Even if 1m away, if the

electromagnetic wave is too strong, it can also cause noise.)

(2) The height of ceiling

The indoor unit can install on the ceiling, which height is no more than 3m.

(3) Install and use the hoisting screw. Check if the installation place can bear the weight of unit assembly. If not

certain, strengthen it before install the unit.

(600x600)

Over 100 Over 900

Air out

Air in

Checking meatus

Ceiling

Over 300Over 200

Installation Precedure

Indoor Unit
