middle of the guides, move the upper edging-strip

guide up or down until the edging-strip runs freely with

the least possible play. The lower edging-strip guide

is factory-set to provide enough excess material to

enable the board to be trimmed later on.

The motor-driven trimmer is not supplied with model

EB5C, though it can be added as an optional extra.

The EB10C model comes from the factory complete

with the motor-driven trimmer, it being necessary

to adjust the blades U (Fig. 7) when adjusting the

edging-strip width.

The control panel is located on the front of the

machine, and it has a heater starter switch X, which

also turns on the automatic edging-strip cutter. Button

Y is for adjusting the heater temperature (Fig. 1).

To prepare the machine for work, press the switch X

(the pilot light comes on) and set button Y to point 1

to stop the temperature rising. Then feed the edging-

strip through until the end comes out through the

gluing roller Z (Fig. 8). Cut the edging-strip with the

pedal, pressing the microswitch V (Fig. 8) with your

hand, it being next to this roller, and remove the cut-off

section of the edging-strip - and the machine is now

ready for work.

6. SETTING THE TEMPERATURE

For faster temperature increase, set the electronic

control (Fig. 1) to number 9 on the adjustment scale.

When it reaches 300°C, turn the button to point 5 on

the scale and wait till the needle settles; then readjust

to achieve the temperature required by the preglued

edging-strip in use. When purchasing the preglued

edging-strip, it is a good idea to ask the seller for

guidance on the right working temperature, since this

depends on the type of material used in the edging-

strip (melamine, wood, PVC, etc) and on the glue with

which it is impregnated.

7. STRAIGHT EDGES

The machine is factory-set for this kind of work, and all

that needs to be adjusted is the width of the edging-

strip and the gluing temperature.

When the steps described in the sections

"DESCRIPTION AND START-UP" and "SETTING

THE TEMPERATURE" have been completed,

proceed as follows (Fig. 8):

1. Adjust the extendable supporting section E (Fig. 1)

until the gripper I comes into action applying gentle

pressure on the side of the board. When working with

boards that are too large for the gripper, it should be

removed and remounted the wrong way round so as

not to mislay it.

2. Fit the wood into the guides A1 of the machine,

resting on the plate B1 (Fig. 8).

3. Feed the wood through, pressing gently on the

feeding roller S, until the end of the edging-strip

appears in the gluing roller Z (Fig. 8).

4. Press the gluing rollers C1 and maintain a constant

feed speed for perfect gluing (Fig. 1)

C 9075003 Allen bolt M.8x35 2

D 3821046 Extender shaft 2

E 3821049 Moveable supporting arm 2

F 1650024 Edging-strip feeder unit 1

G 1650069 Feeder support unit 1

H 8070027 Aut. bolt 2

I 1650033 Presser set 1

These items must be assembled as shown in (Figs.

1 & 2).

5. DESCRIPTION AND START-UP

5.1 MOVEABLE SUPPORT UNIT

Insert the moveable supporting arms E (Fig. 3) into

the guides J tted on the sides of the table, leaving

them free to move.

One of the ends of the arms E has the bolt C, the

washers B and the shaft D.

Remove the bolts C and the washer B from the

supporting arms E.

Fit the moveable section A in the supporting arms

E and x in place with the washer B and the bolt C

(Fig. 4).

Move the supporting unit A until it meets the table

section K. Tighten levers L.

Loosen bolts C, bring section A ush with section K

and retighten bolts C.

Loosen levers L and check the movement of the unit

in the guides.

5.2 FITTING THE EDGING-STRIP FEEDER UNIT

Fit the feeder unit bracket in place using bolts H.

Attach the feeder F into the feeder support shaft.

Check the edging-strip entry height, adjusting it with

bolt G (Fig. 5).

5.3 LOCATION AND START-UP

The machine must be placed on a workbench, its

base being fastened down using the holes provided

(Fig. 6).

The machine has a STOP-START switch M (Fig. 2)

tted on the back. This switch provides protection

against involuntary starting-up of the machine,

and also acts as the power intake, the machine

being connected to the mains by way of an earthed

extension cable with conductor cables of a suitable

type for a rated current of 16 A.

Place the preglued edging-strip reel in the feeder F

(Fig. 5), the width of the strip matching the board to be

edged. It is advisable to choose a preglued strip whose

width is 3 mm greater than the board width.

Pass the end of the edging-strip roll through the

drawing rollers N, via the channeler P (Fig. 1), the

latter having been preadjusted so that the edging-

strip slips through without jamming and with consistent

play.

Using knob R located on top of the feeder reel S (Fig.

1) (Fig. 9), feed the edging-strip through until it goes

into the guides. Using knob T (Fig. 9) located in the
