Setting the Codes

Make sure that the instrument is switched off before setting the codes.

• Remove the batteries from the transmitter in compliance with section 8.2.

• Remove the jumper within the battery case (6 a).

• Place the batteries respecting correct polarity.

• Switch on the transmitter pressing button 5.

• Select the required code using button 4

Code selection can be made as follows (A, F, E, H, O, O, C).

• Switch off the transmitter using button 5, remove the batteries, and reset the jumper

• Replace the transmitter batteries and the battery case.

• The instrument is now ready for use and the code is newly set.

Measurement Point Illumination

Press button 13 for measurement point illumination (10).The instrument switches off automatically

after approximately 60 seconds or it can be switched off manually when pressing the button 13

again.

Maintenance

When using the instrument in compliance with the Users Manual, no special maintenance is requi-

red. For any queries regarding the instrument, please always quote product designation and serial

number, both marked on the type shield label on instrument rear. If functional errors occur after ex-

piration of warranty, our after sales service will repair your instrument without delay.

Cleaning

If the instrument is dirty after daily usage, clean it by using a wet cloth and a mild household deter-

gent.

Prior to cleaning, ensure that instrument is switched off and disconnected from external voltage

supply and any other instruments connected (such as UUT, control instruments, etc.).

Never use acid detergents or dissolvants for cleaning.

Battery Replacement

The batteries have to be changed, when the symbols (3 d-Transmitter/ 9 c-Receiver) are displayed.

Prior to storage battery replacement, disconnect the instrument from any connected test leads.

Please refer to the description on the bottom of the battery case for correct layout of batteries.
