Installing the awning PR2000, PR2500

Installing the wall bracket

The wall bracket must be installed if the awning is to be attached to the side

of the vehicle when extended.

➤ Select the location of the installation.

➤ Mark where the holes are to be drilled.

➤ At the marked points, drill holes with a diameter of 3 mm from the outside

into the external wall (fig. 5, page 4).

➤ Put the upper and lower sections of the wall bracket together.

➤ Clean the outer sides of the lower section and the installation surface in

the vehicle.

➤ To glue and seal, apply an elastic adhesive, such as Sikaflex®-221 for

example, to the back of the wall bracket.

➤ Fasten the wall bracket with drill screws (fig. 5, page 4).

➤ Rivet the wall bracket in place (fig. 5, page 4).

Installing the crank bracket

➤ Install the wall bracket for the crank at a suitable location inside the

vehicle (fig. 6, page 5).

Mounting the tensioning arm

Awnings with a width of 4 m to 5.5 m must be secured using a tensioning

arm.

➤ Attach the pre-drilled end of the tensioning arm to the latch for the

tensioning arm using the hexagon head bolt and the hexagon nut with

clamping part (fig. 7, page 6).

➤ Insert the lower section of the tensioning arm into the upper section

(fig. 7, page 6).

NOTE

Make sure that no glue gets on to the movable upper section of

the wall bracket.
