4.5 HANDLING OF THE LED ILLUMINATION

TheLEDilluminationpreinstalledinthefrontcanbeconguredinseveralcolorsandoperatingmodes.Further

strips of LED illumination for lighting the case interior can be plugged into socket “D” on LED controller PCB

(4.3) with a maximum combined rating of 24 watts.

WARNING! Only 12V LEDs may be connected.

To switch between synchronized operation and manual control mode keep switch “G“ pressed for about three

seconds.

Synchronized operation

It is possible to connect cable “C” of the PCB (4.3) and the corresponding RGB LED controller socket of your

motherboard. The integrated illumination can then be controlled by the motherboard.

For information on operation of the LED controller of your motherboard refer to your motherboard handbook.

Inmanualmodeyoucancyclethroughtheavailablecolors(white,red,green,blue,orange,purple)bybriey

pressing switch “G”. An intermediate stage between each color enables “breath mode” for the previously

selected color.

The individual switch stages are:

1 White 8 Blue breath

2 White breath 9 Orange

3 Red 10 Orange breath

4 Red breath 11 Purple

5 Green 12 Purple breath

6 Green breath 13 Breath mode alternately in all colors

7 Blue 14 LEDso
