Type Code Frame

Input

Amps

MMP Type E

1, 2

Min. Encl.

Vol. (cu in)

3 Phase 380, 400, 415V (continued)

ACS355-03x-07A3-4 R1 12.0 MS451-16E 1152

ACS310-03x-08A0-4 R1 12.8 MS451-16E 1152

ACS150/320-03x-08A8-4 R1 13.6 MS451-16E 1152

ACS355-03x-08A8-4 R1 14.0 MS451-16E 1152

ACS310-03x-09A7-4 R1 15.0 MS451-20E 1152

ACS320-03x-12A5-4 R3 18.8 MS451-20E -

ACS150/355-03x-12A5-4 R3 19.0 MS451-20E -

ACS310-03x-13A8-4 R3 20.7 MS451-25E -

ACS150/355-03x-15A6-4 R3 22.0 MS451-25E -

ACS320-03x-15A6-4 R3 22.1 MS451-25E -

ACS310-03x-17A2-4 R3 24.3 MS451-32E -

ACS320-03x-23A1-4 R3 30.9 MS451-40E -

ACS150/355-03x-23A1-4 R3 31.0 MS451-32E -

ACS310-03x-25A4-4 R3 34.0 MS451-40E -

ACS150/320/355-03x-31A0-4 R4 52.0 MS495-63E -

ACS310-03x-34A1-4 R4 57.0 MS495-63E -

ACS150/320/355-03x-38A0-4 R4 61.0 MS495-63E -

ACS310-03x-41A8-4 R4 67.0 MS495-75E -

ACS150/320/355-03x-44A0-4 R4 67.0 MS495-75E -

ACS310-03x-48A4-4 R4 74.0 MS495-90E -

3 Phase 440, 460, 480V

ACS150/320/355-03x-01A2-4 R0 1.8 MS132-2.5 & S1-M3-25

1152

ACS310-03x-01A3-4 R0 2.0 MS132-2.5 & S1-M3-25

1152

ACS150/320/355-03x-01A9-4 R0 3.0 MS132-4.0 & S1-M3-25

1152

ACS310-03x-02A1-4 R0 3.3 MS132-4.0 & S1-M3-25

1152

ACS150/320/355-03x-02A4-4 R1 3.4 MS132-4.0 & S1-M3-25

1152

ACS310-03x-02A6-4 R1 3.8 MS132-6.3 & S1-M3-25

1152

ACS150/320/355-03x-03A3-4 R1 5.0 MS132-6.3 & S1-M3-25

1152

ACS310-03x-03A6-4 R1 5.5 MS132-6.3 & S1-M3-25

1152

ACS150/320/355-03x-04A1-4 R1 5.8 MS132-6.3 & S1-M3-25

1152

ACS310-03x-04A5-4 R1 6.3 MS132-10 & S1-M3-25

1152

ACS150/320/355-03x-05A6-4 R1 8.0 MS132-10 & S1-M3-25

1152

ACS310-03x-06A2-4 R1 8.8 MS132-10 & S1-M3-25

1152

ACS150/320/355-03x-07A3-4 R1 9.7 MS132-10 & S1-M3-25

1152

ACS310-03x-08A0-4 R1 11.0 MS451-16E 1152

ACS320/355-03x-08A8-4 R1 11.0 MS451-16E 1152

ACS150-03x-08A8-4 R1 11.3 MS451-16E 1152

ACS310-03x-09A7-4 R1 12.0 MS451-16E 1152

ACS320/355-03x-12A5-4 R3 16.0 MS451-20E -

ACS310-03x-13A8-4 R3 17.0 MS451-20E -

ACS320/355-03x-15A6-4 R3 18.0 MS451-20E -

ACS310-03x-17A2-4 R3 20.0 MS451-25E -

ACS320/355-03x-23A1-4 R3 26.0 MS451-32E -

ACS310-03x-25A4-4 R3 28.0 MS451-32E -

ACS320/355-03x-31A0-4 R4 43.0 MS451-45E -

ACS310-03x-34A1-4 R4 48.0 MS451-50E -

ACS320/355-03x-38A0-4 R4 51.0 MS495-63E -

ACS310-03x-41A8-4 R4 56.0 MS495-63E -

ACS320/355-03x-44A0-4 R4 56.0 MS495-63E -

ACS310-03x-48A4-4 R4 61.0 MS495-63E -

NOTES:

1) All manual motor protectors listed are Type E self-protected up to 65kA. See ABB publication AC1010 for complete technical data on ABB Type E manual motor protectors.

2) Manual motor protectors may require adjusting the trip limit from the factory setting at or above the drive input Amps to avoid nuisance tripping. If the manual motor protector is set to the maximum

current trip level and nuisance tripping is occurring, then select the next size MMP. (MS132-10 is the highest size in MS132 frame size to meet Type E at 65kA; the next size up is the MS451-16E)

3) Requires use of the S1-M3-25 line side feeder terminal with the manual motor protector to meet Type E self-protection class.

4) 480Y/277V only

5) Drives using an ABB Type E Manual Motor Protector and noted with a minimum enclosure size must be installed in a ventilated or non-ventilated enclosure having the minimum volume specied in the

table. For all drives, the enclosure must be sized to accommodate the specic thermal considerations of the application as well as provide free space for cooling. See the applicable ABB User Manual

for free space requirements.

To obtain the most current product documentation go to www.abb.com and select Offerings/Low Voltage AC Drives to navigate to the complete User Manual for the appropriate drive

3AUA0000173741 Effective 12/1/2014
